Metelli PA1134 Engine Water Pump

Brand Metelli PA1134
Bearing Outside Diameter 30
Bearing Type Ball/Ball
Gasket Or Seal Included YES
Housing Material Aluminium
Impeller Material Metal
Impeller Outside Diameter 55.8
Impeller Vane Quantity 7
New Or Remanufactured NEW
Package Contents Water Pump, Gasket
Fits Scion, Toyota, and Pontiac · 20 vehicles

New water pump. Includes a gasket for a ready-to-install replacement.

Aluminium housing. Lightweight construction helps support reliable cooling performance.

Metal impeller. Seven vanes help move coolant efficiently.

Cross-references Airtex AW6351, Beck/Arnley 131-2422 and Dayco DP1442 for the same application. See all 39.

$40.17Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing β€” free returns if it doesn't
Step 2 — Quantity
Order total $40.17
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Engine Water Pump for Toyota and Scion

The Metelli PA1134 engine water pump is a new replacement pump built for cooling system service on select Toyota, Scion, and Pontiac applications. It uses an aluminum housing, a metal impeller, and ball/bal bearing support to help maintain coolant circulation in the engine cooling system.

  • New engine water pump with gasket included
  • Aluminum housing for durable cooling system service
  • Metal impeller with 7 vanes
  • Ball/bal bearing design
  • Impeller outside diameter: 55.8 mm
  • Bearing outside diameter: 30 mm
  • Metelli PA1134 replacement part

Detailed Product Overview

Metelli PA1134 is an OE-style engine water pump for vehicles that require consistent coolant flow through the engine. The metal impeller and 7-vane design support circulation, while the aluminum housing provides a lightweight, corrosion-resistant construction for cooling system use. This part cross-references Airtex AW6351 and Beck/Arnley 131-2422 for the same application. It is a direct-fit replacement for select 2008-2014 Scion xD, 2009-2014 Toyota Corolla, 2009-2013 Toyota Matrix, and 2009-2010 Pontiac Vibe applications.

Common Cooling System Issues

  • Coolant circulation loss from a worn pump
  • Overheating caused by pump bearing wear
  • Coolant leakage at the pump sealing surface
  • Noisy operation from damaged internal bearings
  • Reduced cooling performance from impeller wear

Installation Notes and Tips

Replace the gasket during installation and inspect the mating surfaces before assembly. Flush the cooling system if contamination or old coolant is present, and verify belt condition, pulley alignment, and coolant level after installation. Confirm vehicle application by year, make, and model before ordering the Metelli PA1134.

Quality Assurance

Metelli supplies new cooling components built to match the listed application requirements for Toyota Corolla, Toyota Matrix, Scion xD, and Pontiac Vibe fitments. The PA1134 is a new part with gasket included for service replacement.

Fitment

  • Fits 2008-2014 Scion xD, N/A
  • Fits 2009-2014 Toyota Corolla, N/A
  • Fits 2009-2013 Toyota Matrix, N/A
  • Fits 2009-2010 Pontiac Vibe, N/A
This part fits 20 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersPositionNotes
2014ScionxD1.8LL4N/A—
2014ToyotaCorolla1.8LL4N/A—
2013ScionxD1.8LL4N/A—
2013ToyotaCorolla1.8LL4N/A—
2013ToyotaMatrix1.8LL4N/A—
2012ScionxD1.8LL4N/A—
2012ToyotaCorolla1.8LL4N/A—
2012ToyotaMatrix1.8LL4N/A—
2011ScionxD1.8LL4N/A—
2011ToyotaCorolla1.8LL4N/A—
2011ToyotaMatrix1.8LL4N/A—
2010PontiacVibe1.8LL4N/A—
2010ScionxD1.8LL4N/A—
2010ToyotaCorolla1.8LL4N/A—
2010ToyotaMatrix1.8LL4N/A—
2009PontiacVibe1.8LL4N/A—
2009ScionxD1.8LL4N/A—
2009ToyotaCorolla1.8LL4N/A—
2009ToyotaMatrix1.8LL4N/A—
2008ScionxD1.8LL4N/A—
Directly replaces or cross-references 39 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Airtex — AW6351Beck/Arnley — 131-2422Dayco — DP1442Dorman - HELP — 41033Four Seasons — 66926OSC — 1887US Motor Works — US62328MP37681031451-2512191916100-0950116100-3946516100-39466930655069829410339876471084502553805491086001303930132200016A120E7169SADT391106CP6351DP401FWP2270GWT-144AP7647PA1510PA10196PQ-274T-160T-168T1237TW-5140VKPC91825WP-2281WPT-140WPT-140V
