Metelli PA1228 Engine Water Pump

Brand Metelli PA1228
Pulley Included No
Gasket Or Seal Included Yes
Housing Material Aluminium
Impeller Material Metal
Bearing Type Roller/ball
Impeller Vane Quantity 8
Impeller Outside Diameter 45
New Or Remanufactured New
Package Contents Water pump, gasket
Fits Audi, Porsche, and Volkswagen · 63 vehicles

New water pump. Includes a gasket for a complete replacement.

Aluminium housing. Metal impeller and roller/ball bearing construction.

Eight-vane impeller. Promotes efficient coolant flow through the pump.

Cross-references 06E 121 016C, 06E 121 016CX and 06E 121 016F for the same application. See all 14.

$98.55Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $98.55
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Engine Water Pump for Audi, Porsche, and Volkswagen

Metelli PA1228 is a new engine water pump built for cooling-system service on select Audi, Porsche, and Volkswagen applications. It features an aluminium housing, a metal impeller with 8 vanes, and roller/ball bearing support for dependable coolant circulation.

Compatible With 2011-2019 Audi Q7, A6 Quattro, A7 Quattro, A8 Quattro, S4, S5, SQ5, Q5, A6, and A7; 2012-2018 Porsche Cayenne; 2012-2016 Porsche Panamera; and 2011-2015 Volkswagen Touareg. Part number PA1228 is also a direct reference point for cross-checking OE-style replacement needs.

  • New engine water pump for cooling-system repair
  • Aluminium housing for corrosion-resistant construction
  • Metal impeller with 8 vanes for coolant flow control
  • Roller/ball bearing design for rotating support
  • Gasket included for sealing at installation
  • No pulley included

Detailed Product Overview

Metelli PA1228 is engineered as a replacement water pump for vehicles that rely on stable coolant circulation to manage engine temperature. The metal impeller measures 45 mm outside diameter and uses an 8-vane layout to move coolant through the system, while the aluminium housing supports a durable, service-ready assembly. This part number, PA1228, is listed with gasket included and is supplied new, not remanufactured.

This part cross-references Porsche/Audi applications such as 95810603311 and 06E 121 016C for the same application.

Common Problems This Part Addresses

  • Coolant leakage at the pump housing or seal surface
  • Overheating caused by reduced coolant circulation
  • Noise or rough operation from worn pump bearings
  • Impeller wear that limits coolant movement
  • Cooling-system service needs on Audi Q7, Porsche Cayenne, and Volkswagen Touareg platforms

Installation Notes and Tips

Replace the gasket during installation and verify that the mounting surface is clean and free of old seal material. Confirm pulley reuse requirements before beginning service, since this pump does not include a pulley. Always inspect the cooling system for contamination, hose condition, and thermostat-related issues before returning the vehicle to service.

Quality Assurance

Metelli PA1228 is a new replacement water pump built with an aluminium housing, metal impeller, and bearing-supported shaft assembly for consistent cooling-system service. Verify vehicle application by year, make, and model before ordering.

This part fits 63 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersPositionNotes
2019AudiQ73.0LV6N/A—
2018AudiA6 Quattro3.0LV6N/A—
2018AudiA7 Quattro3.0LV6N/A—
2018AudiA8 Quattro3.0LV6N/A—
2018AudiQ73.0LV6N/A—
2018AudiS43.0LV6N/A—
2018AudiS53.0LV6N/A—
2018AudiSQ53.0LV6N/A—
2018PorscheCayenne3.0LV6N/A—
2017AudiA6 Quattro3.0LV6N/A—
2017AudiA7 Quattro3.0LV6N/A—
2017AudiA8 Quattro3.0LV6N/A—
2017AudiQ53.0LV6N/A—
2017AudiQ73.0LV6N/A—
2017AudiS43.0LV6N/A—
2017AudiS53.0LV6N/A—
2017AudiSQ53.0LV6N/A—
2017PorscheCayenne3.0LV6N/A—
2016AudiA63.0LV6N/A—
2016AudiA6 Quattro3.0LV6N/A—
2016AudiA73.0LV6N/A—
2016AudiA7 Quattro3.0LV6N/A—
2016AudiA8 Quattro3.0LV6N/A—
2016AudiQ5——N/A—
2016AudiS43.0LV6N/A—
2016AudiS53.0LV6N/A—
2016AudiSQ53.0LV6N/A—
2016PorscheCayenne3.0LV6N/A—
2016PorschePanamera3.0LV6N/A—
2015AudiA6 Quattro3.0LV6N/A—
2015AudiA7 Quattro3.0LV6N/A—
2015AudiQ5——N/A—
2015AudiS43.0LV6N/A—
2015AudiS53.0LV6N/A—
2015AudiSQ53.0LV6N/A—
2015PorscheCayenne3.0LV6N/A—
2015PorschePanamera3.0LV6N/A—
2015VolkswagenTouareg3.0LV6N/A—
2014AudiA6 Quattro3.0LV6N/A—
2014AudiA7 Quattro3.0LV6N/A—
2014AudiA8 Quattro3.0LV6N/A—
2014AudiQ5——N/A—
2014AudiS43.0LV6N/A—
2014AudiS53.0LV6N/A—
2014AudiSQ53.0LV6N/A—
2014PorscheCayenne3.0LV6N/A—
2014PorschePanamera3.0LV6N/A—
2014VolkswagenTouareg3.0LV6N/A—
2013AudiA6 Quattro3.0LV6N/A—
2013AudiA7 Quattro3.0LV6N/A—
2013AudiA8 Quattro3.0LV6N/A—
2013AudiQ5——N/A—
2013AudiS43.0LV6N/A—
2013AudiS53.0LV6N/A—
2013PorscheCayenne3.0LV6N/A—
2013PorschePanamera3.0LV6N/A—
2013VolkswagenTouareg3.0LV6N/A—
2012AudiA6 Quattro3.0LV6N/A—
2012AudiA7 Quattro3.0LV6N/A—
2012PorscheCayenne3.0LV6N/A—
2012PorschePanamera3.0LV6N/A—
2012VolkswagenTouareg3.0LV6N/A—
2011VolkswagenTouareg3.0LV6N/A—
Directly replaces or cross-references 14 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
06E 121 016C06E 121 016CX06E 121 016F06E 121 016G06E 121 016Q06E 121 018F06E 121 018FX06E 121 018H06E 121 018K95810603311958106033129581060331395810603314PAC121018A
