Metelli PA1268 Engine Water Pump

Engine Water Pump for Mercedes-Benz Sprinter

Metelli PA1268 is a new engine water pump built for cooling-system service on select Mercedes-Benz Sprinter 2500 and Sprinter 3500 vans. It includes a pulley and gasket, with an aluminium housing and a metal impeller for direct-fit replacement work.

Key Features

• Fits 2014-2017 Mercedes-Benz Sprinter 2500, w/Smooth Pulley
• Fits 2014-2017 Mercedes-Benz Sprinter 3500, w/Smooth Pulley
• New water pump assembly with pulley included
• Gasket included in the package contents
• Aluminium housing with metal impeller
• 9-vane impeller design
• Ball/Ball bearing type
• Impeller outside diameter: 82
• Pulley width: 34.8

Detailed Description

Metelli PA1268 is an engine water pump for cooling-system replacement on Mercedes-Benz Sprinter 2500 and Mercedes-Benz Sprinter 3500 models equipped with a smooth pulley. The pump is supplied new, with a pulley and gasket included, and uses an aluminium housing paired with a metal impeller for service on the specified applications. This part cross-references OE-style numbers such as 651 200 02 02 and A651 200 03 01 for the same application.

Common Replacement Reasons

• Coolant leakage at the pump housing or seal area
• Noise from worn ball bearings
• Reduced coolant circulation from impeller wear
• Overheating caused by water pump failure
• Service replacement on high-mileage Mercedes-Benz Sprinter cooling systems

Installation Notes

Verify smooth-pulley configuration before ordering. Confirm pulley width, bearing dimensions, and impeller specifications against the original unit before installation. Replace the gasket during service and inspect the cooling system for contamination, belt condition, and related wear before returning the vehicle to service.

Quality Assurance

Metelli PA1268 is a new replacement water pump built to match the listed fitment and component specifications for Mercedes-Benz Sprinter applications.
