Metelli PA860 Engine Water Pump

Brand Metelli PA860
Bearing Outside Diameter 38.1
Bearing Type Roller/Ball
Gasket Or Seal Included YES
Housing Included YES
Housing Material Aluminium
Impeller Material Cast Iron
Impeller Outside Diameter 60
Impeller Vane Quantity 6
New Or Remanufactured NEW
Package Contents Water Pump, Gasket
Pulley Groove Quantity 6
Pulley Included YES
Pulley Width 29.2
Fits Lexus and Mini · 31 vehicles

Complete pump assembly. Includes housing, pulley, and gasket for a simpler install.

Aluminium housing. Lightweight construction with a cast iron impeller for durability.

Roller/ball bearing. Built for smooth, reliable pump operation.

Cross-references Airtex AW6338, Airtex AW9474 and Baldwin PA10025 for the same application. See all 54.

$126.34Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $126.34
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Engine Water Pump for Lexus and Mini Applications

Metelli PA860 is a new engine water pump built with an aluminium housing, cast iron impeller, and included gasket for a direct replacement service part. It also includes the pulley and seal, with a 6-groove pulley layout for vehicles that use this configuration.

Compatible With 2002-2008 Mini Cooper, 2007-2013 Lexus LS460, 2008-2013 Lexus LS600h, 2008-2014 Lexus IS F, and 2008-2011 Lexus GS460. Metelli PA860 is a practical choice when replacing a worn cooling system pump on these applications.

Key Features

  • Brand: Metelli
  • Part number: PA860
  • Engine water pump assembly
  • Housing included
  • Pulley included
  • 6-groove pulley design
  • Gasket or seal included
  • Aluminium housing construction
  • Cast iron impeller
  • Roller/ball bearing type
  • New replacement part
  • Package contents: water pump and gasket

Detailed Description

Metelli PA860 is an engine water pump engineered for cooling system service on select Lexus and Mini vehicles. The pump features an aluminium housing for corrosion resistance and a cast iron impeller with 6 vanes to move coolant through the engine cooling circuit. The included pulley and 6-groove pulley width help match the original belt-drive setup on supported applications. This part number, PA860, is listed for Lexus IS F, LS460, LS600h, GS460, and Mini Cooper fitments.

This part cross-references Airtex AW6338 and GMB 115-2240 for the same application.

What This Water Pump Helps Address

  • Coolant circulation problems caused by a worn pump
  • Overheating from reduced water pump performance
  • Coolant seepage at the pump housing or seal area
  • Bearing noise from a failing pump assembly
  • Belt-drive service needs on the front accessory system

Installation Notes and Tips

  • Verify engine code, pulley alignment, and belt routing before installation.
  • Inspect the cooling system, hoses, thermostat, and drive belt during replacement.
  • Clean the mounting surface thoroughly before fitting the included gasket.
  • Confirm the 6-groove pulley configuration matches the vehicle’s original setup.
  • Refill and bleed the cooling system according to the vehicle service procedure.

Quality Assurance

Metelli PA860 is supplied as a new replacement water pump with housing, pulley, gasket, and seal included. Its aluminium housing, cast iron impeller, and roller/ball bearing construction support consistent cooling-system service on the listed Lexus and Mini applications.

This part fits 31 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersPositionNotes
2014LexusIS F5.0LV8N/A—
2013LexusIS F5.0LV8N/A—
2013LexusLS4604.6LV8N/A—
2013LexusLS600h5.0LV8N/A—
2012LexusIS F5.0LV8N/A—
2012LexusLS4604.6LV8N/A—
2012LexusLS600h5.0LV8N/A—
2011LexusGS4604.6LV8N/A—
2011LexusIS F5.0LV8N/A—
2011LexusLS4604.6LV8N/A—
2011LexusLS600h5.0LV8N/A—
2010LexusGS4604.6LV8N/A—
2010LexusIS F5.0LV8N/A—
2010LexusLS4604.6LV8N/A—
2010LexusLS600h5.0LV8N/A—
2009LexusGS4604.6LV8N/A—
2009LexusIS F5.0LV8N/A—
2009LexusLS4604.6LV8N/A—
2009LexusLS600h5.0LV8N/A—
2008LexusGS4604.6LV8N/A—
2008LexusIS F5.0LV8N/A—
2008LexusLS4604.6LV8N/A—
2008LexusLS600h5.0LV8N/A—
2008MiniCooper1.6LL4N/A—
2007LexusLS4604.6LV8N/A—
2007MiniCooper1.6LL4N/A—
2006MiniCooper1.6LL4N/A—
2005MiniCooper1.6LL4N/A—
2004MiniCooper1.6LL4N/A—
2003MiniCooper1.6LL4N/A—
2002MiniCooper1.6LL4N/A—
Directly replaces or cross-references 54 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Airtex — AW6338Airtex — AW9474Baldwin — PA10025Beck/Arnley — 131-2371Dayco — DP277Dorman - HELP — 43535Four Seasons — 20969Four Seasons — 55000Four Seasons — 98221Gates — 20823Gates — 65006GMB — 115-2240Saleri — PA1121US Motor Works — US94743-93758MP37680521111 51 1 485 84611 51 7 510 80311 51 7 513 06211 51 7 829 91411 51 7 829 92211 93 439251-223619912166450678894353598081155240489552581795380158108600119663132200003350981861000ADB119103AQ-1262CP9474CWP-2248CWP-9375FP7532FWP1942Mar-75P412PQ-0118PWP-9375PWP83528T3126VKPA88300WE-BM10WP-2248WP-9375WP0711WP2430WP2649
