Metelli PA912 Engine Water Pump

Brand Metelli PA912
Bearing Outside Diameter 30
Bearing Type Ball/Ball
Gasket Or Seal Included YES
Housing Material Aluminium
Impeller Material Metal
Impeller Outside Diameter 56
Impeller Vane Quantity 7
New Or Remanufactured NEW
Package Contents Water Pump, Sealing paste
Fits Toyota, Lexus, Pontiac, and Scion · 50 vehicles

New water pump. Fresh replacement part for cooling system service.

Aluminium housing. Lightweight construction with a metal impeller.

Seal included. Comes with a gasket or seal for installation.

Cross-references Airtex AW9414, Baldwin PA10047 and Beck/Arnley 131-2272 for the same application. See all 55.

$34.33Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Order total $34.33
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.

Metelli PA912 Engine Water Pump

The Metelli PA912 engine water pump is a new replacement water pump built with an aluminium housing, metal impeller, and ball/ball bearing design. It includes a gasket or seal and sealing paste for service-ready installation on select Toyota, Lexus, Pontiac, and Scion applications.

Key Features

  • New engine water pump for cooling system service
  • Aluminium housing for durable fitment and corrosion resistance
  • Metal impeller with 7 vanes for coolant circulation
  • Ball/ball bearing construction for smooth shaft support
  • Gasket or seal included
  • Package contents: water pump and sealing paste
  • Metelli PA912 cross-references Airtex AW9414 for the same application

Detailed Product Overview

Built for cooling system repair, the Metelli PA912 water pump is engineered with a 56 mm impeller outside diameter and a 30 mm bearing outside diameter. The metal impeller and aluminium housing support dependable coolant flow, while the ball/ball bearing design helps maintain stable pump operation under normal engine conditions. This part number, PA912, is listed for a wide range of Toyota and related platform vehicles, including Toyota Camry, Corolla, RAV4, Highlander, Solara, Matrix, Lexus HS250h, Pontiac Vibe, and Scion tC.

Compatible With 2002-2011 Toyota Camry, 2001-2008 Toyota RAV4, 2001-2007 Toyota Highlander, 2002-2008 Toyota Solara, 2009-2013 Toyota Matrix, 2009-2010 Toyota Corolla, 2010-2012 Lexus HS250h, 2009-2010 Pontiac Vibe, and 2005-2010 Scion tC. The PA912 is a practical choice when replacing a worn or leaking water pump on these applications.

Common Repair Uses

  • Coolant leakage from the water pump housing or seal area
  • Overheating caused by reduced coolant circulation
  • Noise from a worn pump bearing
  • Impeller wear that limits coolant movement
  • Cooling system service on Toyota Camry, Corolla, RAV4, Highlander, Solara, Matrix, Lexus HS250h, Pontiac Vibe, or Scion tC

Installation Notes and Tips

Before installation, verify engine application by year, make, and model against the vehicle’s cooling system configuration. Clean the mounting surface thoroughly, inspect the mating components, and use the included gasket or seal with the supplied sealing paste as directed by the service procedure. After installation, refill and bleed the cooling system to remove trapped air and confirm proper coolant circulation.

Quality Assurance

Metelli PA912 is a new replacement water pump built with specified housing, impeller, and bearing materials for consistent service fitment. It also cross-references Airtex AW9414 for the same application.

This part fits 50 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersPositionNotes
2013ToyotaMatrix2.4LL4N/A—
2012LexusHS250h2.4LL4N/A—
2012ToyotaMatrix2.4LL4N/A—
2011LexusHS250h2.4LL4N/A—
2011ToyotaCamry2.4LL4N/A—
2011ToyotaMatrix2.4LL4N/A—
2010LexusHS250h2.4LL4N/A—
2010PontiacVibe2.4LL4N/A—
2010SciontC2.4LL4N/A—
2010ToyotaCamry2.4LL4N/A—
2010ToyotaCorolla2.4LL4N/A—
2010ToyotaMatrix2.4LL4N/A—
2009PontiacVibe2.4LL4N/A—
2009SciontC2.4LL4N/A—
2009ToyotaCamry2.4LL4N/A—
2009ToyotaCorolla2.4LL4N/A—
2009ToyotaMatrix2.4LL4N/A—
2008SciontC2.4LL4N/A—
2008ToyotaCamry2.4LL4N/A—
2008ToyotaRAV42.4LL4N/A—
2008ToyotaSolara2.4LL4N/A—
2007SciontC2.4LL4N/A—
2007ToyotaCamry2.4LL4N/A—
2007ToyotaHighlander2.4LL4N/A—
2007ToyotaRAV42.4LL4N/A—
2007ToyotaSolara2.4LL4N/A—
2006SciontC2.4LL4N/A—
2006ToyotaCamry2.4LL4N/A—
2006ToyotaHighlander2.4LL4N/A—
2006ToyotaRAV42.4LL4N/A—
2006ToyotaSolara2.4LL4N/A—
2005SciontC2.4LL4N/A—
2005ToyotaCamry2.4LL4N/A—
2005ToyotaHighlander2.4LL4N/A—
2005ToyotaRAV42.4LL4N/A—
2005ToyotaSolara2.4LL4N/A—
2004ToyotaCamry2.4LL4N/A—
2004ToyotaHighlander2.4LL4N/A—
2004ToyotaRAV42.4LL4N/A—
2004ToyotaSolara2.4LL4N/A—
2003ToyotaCamry2.4LL4N/A—
2003ToyotaHighlander2.4LL4N/A—
2003ToyotaRAV42.0LL4N/A—
2003ToyotaSolara2.4LL4N/A—
2002ToyotaCamry2.4LL4N/A—
2002ToyotaHighlander2.4LL4N/A—
2002ToyotaRAV42.0LL4N/A—
2002ToyotaSolara2.4LL4N/A—
2001ToyotaHighlander2.4LL4N/A—
2001ToyotaRAV42.0LL4N/A—
Directly replaces or cross-references 55 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Airtex — AW9414Baldwin — PA10047Beck/Arnley — 131-2272Carlson — 41179Continental — 66974Dorman - HELP — 20788GMB — 170-2470Nissens — 96174Nissens — 941179Spectra Premium — 93080Standard Ignition — D-55US Motor Works — US94141-93228MP37680311122-Jan51-2150252-856171316100-0H03016100-2804016100-2804121552124071506843987687554315353805631086001303030132200013350982055000ADT39188AWP-9322CP9414DP300FP7877FWP2039GWT-119AJ1512093Jan-22NP1851P7687PA1321PQ-270PWP9322T-134T1233VKPC91813WP-9322WP0032WP0166WP206WP2521WPT-129WPT-129VWPT-911
