Moog 512243 Wheel Bearing and Hub Assembly - Rear
| Brand | Moog 512243 |
|---|---|
| Position | Rear |
| Anti Lock Brake Sensor Included | Yes |
| Bolt Circle Diameter | 115.000 |
| Brake Pilot Diameter | 70.100 |
| Flange Bolt Hole Quantity | 3 |
| Flange Diameter | 145.500 |
| Flange Offset | 42.100 |
| Hub Pilot Diameter | 59.800 |
| Spline Quantity | 30 |
| Wheel Pilot Diameter | 59.000 |
| Wheel Stud Quantity | 6 |
| Fits | Cadillac · 18 vehicles |
Fast, hassle-free installation. MOOG problem-solving innovations simplify the job.
Reliable performance. Backed by superior materials and rigorous testing.
Wheel bearing and hub assembly. A complete hub solution for driveline and axle service.
Cross-references Centric Parts 402.62008, Centric Parts 402.62008E and Mevotech Supreme H512243 for the same application. See all 19.
Rear Wheel Hub Assembly for Cadillac STS, SRX, CTS
MOOG 512243 is a rear wheel bearing and hub assembly built for select Cadillac applications, including the STS, SRX, and CTS. It combines hub support, wheel mounting, and ABS sensor integration in one service part for direct replacement work.
Key Features
- Rear wheel bearing and hub assembly for select 2004-2011 Cadillac models
- 30-spline hub design with 6 wheel studs
- ABS sensor included for vehicles that require integrated wheel speed sensing
- Hub pilot diameter: 59.800 mm
- Wheel pilot diameter: 59.000 mm
- Brake pilot diameter: 70.100 mm
- Bolt circle diameter: 115.000 mm
- Flange diameter: 145.500 mm
- Flange offset: 42.100 mm
- 3 flange bolt holes for mounting
Detailed Description
MOOG 512243 is engineered as a rear hub assembly for 2004-2007 Cadillac CTS, 2004-2009 Cadillac SRX, and 2005-2011 Cadillac STS. It is built with quality materials and tested for dependable service, while MOOG’s hub design focuses on straightforward installation and accurate fitment. This part cross-references Timken HA590079 and SKF BR930368 for the same application. For shoppers searching for a rear wheel bearing and hub assembly for Cadillac CTS, Cadillac SRX rear hub replacement, or Cadillac STS rear wheel hub assembly, MOOG 512243 is a direct-fit service part to compare by vehicle and position.
Common Repair Uses
- Wheel bearing noise from the rear of the vehicle
- ABS warning light caused by a failing wheel speed sensor or hub signal issue
- Excessive wheel play or looseness at the rear hub
- Uneven wheel rotation or rough hub operation
- Hub corrosion or wear at the mounting surface
Installation Notes and Tips
Confirm rear position, bolt pattern, spline count, and ABS sensor requirements before installation. Match the hub pilot and brake pilot dimensions to the original part, and inspect the mounting surface, axle interface, and wiring path for wear or corrosion. Always verify vehicle-specific fitment for 2004-2007 Cadillac CTS rear, 2004-2009 Cadillac SRX rear, or 2005-2011 Cadillac STS rear before service.
Quality Assurance
MOOG backs this hub assembly with superior materials and testing protocols aimed at consistent performance in daily driving conditions. The part is built to support reliable rear hub service on Cadillac STS, SRX, and CTS applications, with design details intended to simplify replacement and restore proper wheel support.
| Year | Make | Model | Submodel | Drive Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2011 | Cadillac | STS | — | — | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2010 | Cadillac | STS | — | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2009 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2009 | Cadillac | STS | Base | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2008 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2008 | Cadillac | STS | Base | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2008 | Cadillac | STS | Platinum | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2007 | Cadillac | CTS | V | — | 6.0L | V8 | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2007 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2007 | Cadillac | STS | Base | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2006 | Cadillac | CTS | V | — | 6.0L | V8 | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2006 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2006 | Cadillac | STS | Base | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2005 | Cadillac | CTS | V | — | 5.7L | V8 | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2005 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2005 | Cadillac | STS | — | RWD | — | — | Rear | 6 Stud Hub; Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable |
| 2004 | Cadillac | CTS | V | — | 5.7L | V8 | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
| 2004 | Cadillac | SRX | — | — | — | — | Rear | Enhanced Hub Assembly with Grime Defense Outboard Seal, Primary Inboard and Outboard Seals, and molded grommet for ABS cable. |
