Moog 512401E Wheel Bearing and Hub Assembly - Rear
| Brand | Moog 512401E |
|---|---|
| Position | Rear |
| Spline Quantity | 27 |
| Flange Bolt Hole Quantity | 4 |
| Wheel Pilot Diameter | 55.900 |
| Brake Pilot Diameter | 57.900 |
| Wheel Stud Quantity | 5 |
| Hub Pilot Diameter | 83.900 |
| Flange Shape | Modified |
| Anti Lock Brake Sensor Included | No |
| Flange Offset | 66.500 |
| Flange Diameter | 123.900 |
| Bolt Circle Diameter | 100.200 |
| Bolt Circle Diameter | 3.937 |
| Fits | Scion, Subaru, and Toyota · 50 vehicles |
Coated hub assembly. Adds protection for demanding service conditions.
Direct-fit design. Uses application-specific hub dimensions for accurate replacement.
Integrated hub features. Includes pilot diameters and flange geometry for proper location.
Cross-references BCA WE60543, Mevotech Original Grade G512401 and Mevotech Supreme H512401 for the same application. See all 14.
Wheel Bearing and Hub Assembly
Moog 512401E is a coated wheel bearing and hub assembly built for rear applications with direct-fit dimensions and integrated hub features. It is engineered for service work on Subaru, Toyota, and Scion rear hubs where a precise replacement is needed.
- Coated hub assembly for added protection in demanding service conditions.
- Rear wheel bearing and hub assembly with 5 wheel studs and 4 flange bolt holes.
- 27-spline design with a modified flange shape for application-specific fitment.
- Includes an integrated hub pilot, wheel pilot, and brake pilot for accurate component location.
- ABS sensor not included.
Fitment Details
Compatible with rear hub applications on the following vehicles:
- Fits 2022-2025 Subaru BRZ, rear.
- Fits 2013-2020 Subaru BRZ, rear.
- Fits 2022-2023 Toyota GR86, rear.
- Fits 2019-2021 Subaru Crosstrek, rear.
- Fits 2017-2020 Toyota 86, rear.
- Fits 2013-2016 Scion FR-S, rear.
- Fits 2008-2014 Subaru Impreza, rear.
- Fits 2010-2014 Subaru Legacy, rear.
- Fits 2010-2014 Subaru Outback, rear.
- Fits 2013-2014 Subaru WRX STI, rear.
- Fits 2009-2013 Subaru Forester, rear.
- Fits 2013 Subaru WRX, rear.
Installation Notes
Verify spline count, bolt circle diameter, flange dimensions, and pilot diameters before installation. This rear hub assembly is intended for vehicles that use the listed fitment and should be matched to the original hub configuration during service.
Quality Assurance
Moog coated hub assemblies are built with problem-solving enhancements that extend product life and simplify replacement work. Part number 512401E is also cross-referenced to Timken HA590313 for the same application.
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 2025 | Subaru | BRZ | — | Rear | — |
| 2024 | Subaru | BRZ | — | Rear | — |
| 2023 | Subaru | BRZ | — | Rear | — |
| 2023 | Toyota | GR86 | — | Rear | — |
| 2022 | Subaru | BRZ | — | Rear | — |
| 2022 | Toyota | GR86 | — | Rear | — |
| 2021 | Subaru | Crosstrek | Hybrid | Rear | — |
| 2020 | Subaru | BRZ | — | Rear | — |
| 2020 | Subaru | Crosstrek | Hybrid | Rear | — |
| 2020 | Toyota | 86 | — | Rear | — |
| 2019 | Subaru | BRZ | — | Rear | — |
| 2019 | Subaru | Crosstrek | Hybrid | Rear | — |
| 2019 | Toyota | 86 | — | Rear | — |
| 2018 | Subaru | BRZ | — | Rear | — |
| 2018 | Toyota | 86 | — | Rear | — |
| 2017 | Subaru | BRZ | — | Rear | — |
| 2017 | Toyota | 86 | — | Rear | — |
| 2016 | Scion | FR-S | — | Rear | — |
| 2016 | Subaru | BRZ | — | Rear | — |
| 2015 | Scion | FR-S | — | Rear | — |
| 2015 | Subaru | BRZ | — | Rear | — |
| 2014 | Scion | FR-S | — | Rear | — |
| 2014 | Subaru | BRZ | — | Rear | — |
| 2014 | Subaru | Impreza | WRX STI | Rear | — |
| 2014 | Subaru | Legacy | — | Rear | — |
| 2014 | Subaru | Outback | — | Rear | — |
| 2014 | Subaru | WRX STI | Base | Rear | — |
| 2013 | Scion | FR-S | — | Rear | — |
| 2013 | Subaru | BRZ | — | Rear | — |
| 2013 | Subaru | Forester | — | Rear | — |
| 2013 | Subaru | Impreza | WRX | Rear | — |
| 2013 | Subaru | Legacy | — | Rear | — |
| 2013 | Subaru | Outback | — | Rear | — |
| 2013 | Subaru | WRX | Limited | Rear | — |
| 2013 | Subaru | WRX STI | Base | Rear | — |
| 2012 | Subaru | Forester | — | Rear | — |
| 2012 | Subaru | Impreza | WRX | Rear | — |
| 2012 | Subaru | Legacy | — | Rear | — |
| 2012 | Subaru | Outback | — | Rear | — |
| 2011 | Subaru | Forester | — | Rear | — |
| 2011 | Subaru | Impreza | WRX | Rear | — |
| 2011 | Subaru | Legacy | — | Rear | — |
| 2011 | Subaru | Outback | — | Rear | — |
| 2010 | Subaru | Forester | — | Rear | — |
| 2010 | Subaru | Impreza | WRX | Rear | — |
| 2010 | Subaru | Legacy | — | Rear | — |
| 2010 | Subaru | Outback | — | Rear | — |
| 2009 | Subaru | Forester | — | Rear | — |
| 2009 | Subaru | Impreza | WRX | Rear | — |
| 2008 | Subaru | Impreza | WRX | Rear | — |
