Moog 512568 Wheel Bearing and Hub Assembly - Rear

Rear Wheel Bearing Hub Assembly for Jeep and Fiat

MOOG 512568 is a rear wheel bearing and hub assembly built for specific Jeep Compass, Jeep Renegade, and Fiat 500X applications. It combines hub, bearing, and ABS sensor integration in one service part for direct replacement on the rear axle.

Key Features

• Rear wheel bearing and hub assembly for select Jeep Compass, Jeep Renegade, and Fiat 500X models
• Anti-lock brake sensor included for ABS-equipped applications
• 5 wheel studs with a 109.900 bolt circle diameter
• 4 flange bolt holes for mounting
• Wheel pilot diameter: 65.000
• Brake pilot diameter: 69.900
• Hub pilot diameter: 84.000
• Flange diameter: 135.100 with 41.900 flange offset
• MOOG 512568 is engineered with design updates that focus on longer service life and easier installation

Detailed Description

MOOG 512568 is a rear wheel bearing and hub assembly for 2015-2018 Jeep Renegade, 2016-2018 Fiat 500X, 2017 Jeep Compass Mexico Built, and 2018-2022 Jeep Compass rear applications. This assembly is built around the dimensional requirements of the hub and brake interface, including the wheel pilot, brake pilot, hub pilot, flange offset, and bolt circle diameter, to support accurate fitment during replacement. This part cross-references SKF BR931004 for the same application.

As part of MOOG’s chassis and driveline lineup, this hub assembly reflects the brand’s focus on service-friendly design changes that help simplify replacement and extend part life. MOOG 512568 is a direct-fit option for rear wheel bearing service on Jeep Compass and Jeep Renegade platforms, as well as the Fiat 500X rear hub application.

What This Part Helps Address

• Rear wheel bearing noise or roughness
• Wheel hub play or looseness at the rear axle
• ABS warning light concerns tied to the hub sensor circuit
• Uneven wheel rotation caused by worn hub components
• Replacement needs after hub or bearing wear on Jeep Compass, Jeep Renegade, or Fiat 500X rear applications

Installation Notes and Tips

Verify rear axle fitment by year, make, model, and build notes before installation. Confirm the flange bolt hole pattern, bolt circle diameter, and pilot diameters match the original hub assembly, and inspect the mating surfaces, axle hardware, and ABS connector condition during service. For best results, compare the removed part to MOOG 512568 before final assembly.

Quality Assurance

MOOG is known for chassis and driveline parts that incorporate design improvements aimed at easier service and longer product life. Part number 512568 is built for the specified rear applications and follows MOOG’s problem-solving approach to replacement components.
