Moog 513278 Wheel Bearing and Hub Assembly - Front

Front Wheel Bearing Hub Assembly for Hyundai

MOOG 513278 is a front wheel bearing and hub assembly built for select Hyundai Equus and Hyundai Genesis applications. It combines hub, bearing, and ABS sensor integration in one service part to support accurate wheel mounting and dependable front-end operation.

Key Features

• Front wheel bearing and hub assembly for Hyundai Equus and Hyundai Genesis
• Anti-lock brake sensor included for ABS-equipped vehicles
• 5 wheel studs with a 114.3 mm bolt circle diameter
• 4 flange bolt holes for secure mounting
• Wheel pilot diameter: 67.000 mm
• Brake pilot diameter: 69.000 mm
• Hub pilot diameter: 80.000 mm
• Flange diameter: 139.000 mm with 53.400 mm flange offset

Detailed Description

MOOG 513278 is engineered as a direct-fit front hub assembly for 2009-2014 Hyundai Genesis and 2011-2016 Hyundai Equus models. MOOG focuses on design updates that improve service life and make installation and replacement more straightforward, which is why this part is commonly selected for front wheel bearing and hub service on Hyundai Genesis and Hyundai Equus vehicles. This part cross-references SKF BR930725 and Raybestos Brakes 713278 for the same application.

What It Helps Fix

• Front wheel bearing noise such as humming or growling
• Excessive wheel play or looseness at the hub
• ABS warning light concerns related to the hub sensor assembly
• Uneven wheel mounting or hub-related vibration
• Service issues caused by worn front hub components

Installation Notes and Tips

Verify vehicle year, model, and front position before ordering. Confirm bolt circle diameter, pilot diameters, and flange dimensions against the original part to ensure proper fit on Hyundai Genesis and Hyundai Equus applications. Inspect the mating surfaces, axle area, and ABS connector condition during installation, and follow the vehicle service manual for torque specifications and sensor routing.

Quality Assurance

MOOG is known in the chassis and driveline market for ongoing design improvements that support easier service and longer part life. Part number 513278 is built to meet the needs of front hub replacement on the listed Hyundai applications.
