MoogPart #: ES3584
Moog ES3584 Steering Tie Rod End - Inner
52 vehicles fit this part
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
$51.38Free Shipping
Free ShippingNo Cost to Continental U.S.
Free Returns*Wrong fit? No cost
60-Day ReturnsMoney back guarantee
*Free return shipping only qualifies if our fitment verification tool is used.
In Stock · Ready To Ship
Most orders ship same-day if ordered before 1pm CST.
OE Direct Replacement — Bolt-on fit, no modifications needed
Fitment: Chevrolet, GMC, Isuzu, and Oldsmobile, Blazer, Bravada, Hombre, Jimmy, S10, and Sonoma
Easy Returns — Return within 60 days for a full refund
Fast Shipping — Most orders ship same business day before 1pm CST
Not what you need? See all Steering Tie Rod End options
MOOG ES3584 Inner Tie Rod End
MOOG ES3584 is an inner steering tie rod end built for direct replacement on select GM and Isuzu applications. It uses measured thread specifications and a precise stud-to-end length to support accurate steering linkage service on vehicles such as the Chevrolet Blazer, GMC Jimmy, Chevrolet S10, and GMC Sonoma.
Key Features
- Inner tie rod end for steering linkage repair
- End 1 thread direction: counterclockwise
- End 1 threads per inch: 18
- End 2 gender: male
- End 2 thread diameter: 12.0
- End 2 thread pitch: 1.3
- Length stud center to end: 4.530
- Built with materials and testing standards focused on dependable steering performance
- MOOG ES3584 is engineered for straightforward installation on listed applications
Detailed Description
MOOG ES3584 inner tie rod end is a steering component for vehicles that require a counterclockwise-threaded inner linkage end with a 12.0 mm male thread on the outer side. The 4.530-inch stud-center-to-end length and 18 TPI thread specification help match the original steering geometry on supported applications. This part cross-references Beck/Arnley 101-7647 for the same application. MOOG ES3584 is a direct-fit service part for steering repair on the Chevrolet Blazer, GMC Jimmy, Chevrolet S10, GMC Sonoma, Oldsmobile Bravada, and Isuzu Hombre.
Vehicle Fitment
- Fits 1999-2005 Chevrolet Blazer, Inner.
- Fits 1998 Chevrolet Blazer, Inner.
- Fits 2002-2005 GMC Jimmy, Inner.
- Fits 1999-2000 GMC Jimmy, Inner.
- Fits 1998-2001 GMC Jimmy, Inner.
- Fits 1999-2004 Chevrolet S10, Inner.
- Fits 1998 Chevrolet S10, Inner.
- Fits 1999-2004 GMC Sonoma, Inner.
- Fits 1998 GMC Sonoma, Inner.
- Fits 1999-2001 Oldsmobile Bravada, Inner.
- Fits 1999-2000 Isuzu Hombre, Inner.
- Fits 1998 Isuzu Hombre, Inner.
Common Repair Symptoms
- Loose or imprecise steering feel
- Steering play caused by worn inner linkage components
- Uneven tire wear related to steering geometry issues
- Clunking or movement in the steering system
- Difficulty maintaining alignment after steering service
Installation Notes and Tips
Verify thread direction, thread diameter, pitch, and overall length before installation to confirm match with the existing steering linkage. After replacement, a professional wheel alignment is recommended to restore steering geometry and tire wear characteristics. MOOG ES3584 is listed for inner position applications only, so confirm the vehicle’s steering layout before ordering.
Quality Assurance
MOOG backs this inner tie rod end with superior materials and rigorous testing to support reliable steering performance. The brand also incorporates problem-solving design features aimed at making installation faster and less complicated on the listed applications.
| Brand | Moog |
|---|---|
| Part Number | ES3584 |
| End 2 Gender | Male |
| End 2 Thread Diameter | 12.0 |
| End 1 Thread Direction | Counterclockwise |
| End 2 Thread Pitch | 1.3 |
| Length Stud Center to End | 4.530 |
| End 1 Threads Per Inch | 18 |
This part fits 52 vehicles. Search below:
| Year | Make | Model | Submodel | Drive Type | Position | Notes |
|---|---|---|---|---|---|---|
| 2005 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2005 | GMC | Jimmy | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2004 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2004 | Chevrolet | S10 | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2004 | GMC | Jimmy | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2004 | GMC | Sonoma | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2003 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2003 | Chevrolet | S10 | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2003 | GMC | Jimmy | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2003 | GMC | Sonoma | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2002 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2002 | Chevrolet | S10 | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2002 | GMC | Jimmy | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2002 | GMC | Sonoma | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2001 | Chevrolet | Blazer | AWD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2001 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2001 | Chevrolet | S10 | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2001 | GMC | Jimmy | SLE | AWD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2001 | GMC | Jimmy | SLE | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2001 | GMC | Jimmy | Diamond Edition | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2001 | GMC | Sonoma | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2001 | Oldsmobile | Bravada | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 2000 | Chevrolet | Blazer | AWD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2000 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2000 | Chevrolet | S10 | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2000 | GMC | Jimmy | Envoy | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. |
| 2000 | GMC | Jimmy | SLT | AWD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2000 | GMC | Jimmy | SLT | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2000 | GMC | Jimmy | SLS | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 2000 | GMC | Sonoma | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2000 | Isuzu | Hombre | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 2000 | Oldsmobile | Bravada | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 1999 | Chevrolet | Blazer | AWD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 1999 | Chevrolet | Blazer | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 1999 | Chevrolet | S10 | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 1999 | GMC | Jimmy | Envoy | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. |
| 1999 | GMC | Jimmy | SL | AWD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1999 | GMC | Jimmy | SLT | AWD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1999 | GMC | Jimmy | SL | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1999 | GMC | Jimmy | SLT | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1999 | GMC | Jimmy | SLS | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1999 | GMC | Sonoma | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 1999 | Isuzu | Hombre | 4WD | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | |
| 1999 | Oldsmobile | Bravada | Inner | Enhanced lubrication improves steering performance for Suspension Stabilizer Bar Link. | ||
| 1998 | Chevrolet | Blazer | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces | |
| 1998 | Chevrolet | S10 | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces | |
| 1998 | GMC | Jimmy | Envoy | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1998 | GMC | Jimmy | SL | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1998 | GMC | Jimmy | SLT | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1998 | GMC | Jimmy | SLS | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
| 1998 | GMC | Sonoma | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces | |
| 1998 | Isuzu | Hombre | 4WD | Inner | Offset Tie Rod End; Includes Powdered-Metal Gusher Bearing To Allow Grease To Penetrate Bearing Surfaces |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
101-764712471301401-1222534-669612.660218124713010ES2072LES3584JTE1347MES3584T3584TI91220
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
