Moog ES80558 Steering Tie Rod End - Left Inner

MOOG ES80558 Inner Tie Rod End

MOOG ES80558 is an inner tie rod end built for steering service on the 1997-2001 Cadillac Catera, left inner position. It uses a straight design with a 14.0 mm end 1 thread diameter and 1.5 thread pitch for a precise steering linkage connection.

Backed by tested materials and MOOG engineering, this ES80558 inner tie rod end is focused on dependable steering performance and straightforward installation on the Cadillac Catera.

Key Features

• Part number ES80558 inner tie rod end for steering repair
• Fits 1997-2001 Cadillac Catera, left inner
• Straight design for steering linkage replacement
• 14.0 mm end 1 thread diameter
• 1.5 thread pitch for proper thread engagement
• Length from stud center to end: 3.540 in.
• No dust boot included
• Non-greaseable design

Detailed Description

MOOG ES80558 is an inner tie rod end for the steering system on the Cadillac Catera. It is engineered with a straight profile and the specified thread dimensions to match the original steering connection on 1997-2001 Cadillac Catera models in the left inner position. If you are searching for a Cadillac Catera inner tie rod end, ES80558 provides a direct-fit service part reference for steering maintenance.

This part cross-references Monroe Shocks & Struts 172286 and 182286 for the same application. The MOOG ES80558 part number is also commonly used when comparing steering tie rod end replacements for the Cadillac Catera.

What It Helps Address

• Loose or imprecise steering feel
• Wear in the inner steering linkage
• Clunking or play from the steering rack connection
• Uneven steering response caused by worn tie rod components
• Need for a replacement inner tie rod end on the Cadillac Catera

Installation Notes and Tips

Verify left inner fitment before installation and confirm thread diameter and pitch match the original component. Inspect the surrounding steering linkage and alignment condition during service, since tie rod replacement typically affects toe settings. Because this ES80558 design is non-greaseable and does not include a dust boot, reuse or replace related steering components as needed based on inspection.

Quality Assurance

MOOG backs this inner tie rod end with superior materials and rigorous testing to support reliable steering service. The ES80558 is built to meet the demands of routine steering repair on the Cadillac Catera.
