MPA Electrical B5036 Power Brake Booster

Overview

This remanufactured hydraulic power brake booster is built for drivers who need consistent brake assist and reduced pedal effort. It is a standard replacement unit for heavy-duty applications and is listed under part number B5036.

Compatible with Chevrolet P30 and GMC P3500 applications, this booster is also a fit for Chevrolet C3500HD and GMC C3500HD models where the listed hydraulic booster configuration is required. The B5036 is remanufactured and tested to support reliable pressure transfer and vacuum sealing performance.

Key Features

• Hydraulic power brake booster construction for assisted braking performance
• Remanufactured standard replacement design
• Metal housing for durable service use
• Master cylinder is not included
• Brake pedal rod extension, gasket or seal, front seal, and mounting bracket are not included
• Master cylinder stud thread size: 10 x 1.50 mm

Detailed Description

MPA Electrical B5036 is a reman hydraulic power brake booster engineered for applications that require dependable brake assist with minimal pedal effort. The unit uses specially treated replacement components and is end-of-line tested to verify performance before release. For Chevrolet P30 and GMC P3500 platforms, as well as Chevrolet C3500HD and GMC C3500HD applications, this booster provides a direct replacement option when the hydraulic booster setup matches the listed fitment.

The B5036 is supplied without a master cylinder and uses a metal housing with a 10 x 1.50 mm master cylinder stud thread size. This part cross-references 14022299 for the same application.

What It Is Used For

• Restoring brake assist when pedal effort has increased
• Replacing a worn or leaking hydraulic booster assembly
• Addressing inconsistent pressure transfer in the brake system
• Correcting loss of vacuum seal or reduced braking response

Installation Notes and Tips

Verify the hydraulic booster configuration, master cylinder stud thread size, and vehicle application before installation. This unit does not include a master cylinder, brake pedal rod extension, gasket or seal, front seal, or mounting bracket. Confirm all brake system connections and bleed procedures are completed according to service specifications.

Quality Assurance

MPA Electrical subjects each unit to 100% end-of-line testing using proprietary equipment to confirm function before shipment. The remanufactured design is intended to meet standard replacement requirements for the listed applications.
