OE Quality
60-Day Returns
MPA Electrical WH512556 Wheel Bearing and Hub Assembly - Rear
Rear Wheel Hub Assembly for Kia Sedona
MPA Electrical WH512556 is a rear wheel bearing and hub assembly built for Kia Sedona applications from 2015 and 2016-2021. It combines the hub, bearing, flange, and ABS sensor components needed for a direct replacement on the rear axle.
- Fits 2015 Kia Sedona, rear
- Fits 2016-2019 Kia Sedona, rear, Wheel Hub Assembly
- Fits 2020-2021 Kia Sedona, rear
- Flange included with 4 bolt holes and rectangle shape
- ABS sensor included; sensor-type anti-lock braking system
- Steel construction with 5 stud wheel mounting and M12 x 1.5 wheel studs
- Gasket or seal included
- Hub pilot diameter: 3.62 in; flange diameter: 5.476 in; flange offset: 2.1 in
Fitment and Application Details
This MPA Electrical WH512556 wheel bearing and hub assembly is a direct-fit rear replacement for Kia Sedona models listed above. It is built around the OE-style hub and bearing layout with an integrated ABS sensor, making it a practical choice when servicing rear wheel noise, looseness, or sensor-related warning concerns on the Kia Sedona.
This part cross-references Kia 51750-A9000 for the same application.
Common Problems This Part Can Address
- Rear wheel bearing noise such as humming, growling, or rumbling
- Wheel play or looseness at the rear hub
- ABS warning light concerns related to a failed hub sensor
- Uneven wheel rotation caused by hub or bearing wear
- Rear hub corrosion or damage at the mounting flange
Installation Notes and Tips
Confirm rear-position fitment by year before ordering. Inspect the mounting surface, axle area, and ABS connector condition during replacement, and verify proper torque on the flange and wheel fasteners during installation. Because the ABS sensor is included, check sensor alignment and wiring routing before final assembly.
Quality Assurance
MPA Electrical markets this unit as a quality-built hub and bearing assembly. New steel construction, included seal, and integrated ABS sensor support a complete rear hub service for Kia Sedona applications.
| Brand | MPA Electrical |
|---|---|
| Part Number | WH512556 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Flange Shape | Rectangle |
| Anti Lock Braking System Type | Sensor |
| Anti Lock Brake Sensor Included | Yes |
| Flange Offset | 2.1 |
| Flange Diameter | 5.476 |
| Flange Diameter Inch | 5.476 |
| Gasket or Seal Included | Yes |
| Greaseable | No |
| Hub Pilot Diameter Inch | 3.62 |
| Material | Steel |
| Product Condition | New |
| Stud Quantity | 5 |
| Wheel Stud Size MM | M12 x 1.5 |
| Wiring Harness Included | No |
This part fits 7 vehicles. Search below:
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2021 | Kia | Sedona | 3.3L | V6 | Rear | |
| 2020 | Kia | Sedona | 3.3L | V6 | Rear | |
| 2019 | Kia | Sedona | 3.3L | V6 | Rear | Wheel Hub Assembly |
| 2018 | Kia | Sedona | 3.3L | V6 | Rear | Wheel Hub Assembly |
| 2017 | Kia | Sedona | 3.3L | V6 | Rear | Wheel Hub Assembly |
| 2016 | Kia | Sedona | 3.3L | V6 | Rear | Wheel Hub Assembly |
| 2015 | Kia | Sedona | 3.3L | V6 | Rear |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
