MPA Electrical WH515118 Wheel Bearing and Hub Assembly - Front
| Brand | MPA Electrical WH515118 |
|---|---|
| Position | Front |
| Spline Quantity | 45 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Flange Shape | Square |
| Anti Lock Braking System Type | Sensor |
| Anti Lock Brake Sensor Included | Yes |
| Flange Bolt Hole Diameter | 6.3 |
| Flange Offset | 1.796 |
| Flange Diameter | 7.484 |
| Flange Diameter Inch | 7.484 |
| Gasket or Seal Included | Yes |
| Greaseable | No |
| Hub Pilot Diameter Inch | 3.91 |
| Material | Steel |
| Product Condition | New |
| Spline Quantity | 45 |
| Stud Quantity | 7 |
| Wheel Stud Size MM | M14 x 2.0 |
| Wiring Harness Included | No |
| Fits | Ford · 21 vehicles |
Cross-references 9L3Z-1104-C for the same application. See all 1.
$196.77Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Wheel Bearing and Hub Assembly options
MPA Electrical WH515118 Wheel Bearing and Hub Assembly - Front
This part fits 21 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
| Year | Make | Model | Submodel | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2010 | Ford | F-150 | XLT | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | XL | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | Platinum | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | Lariat | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | King Ranch | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | Harley-Davidson Edition | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | FX4 | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | FX2 | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | XLT | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | XL | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | STX | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | FX2 | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2010 | Ford | F-150 | XL | 4.2L | V6 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | XL | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | Platinum | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | Lariat | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | King Ranch | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | FX4 | 5.4L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | XL | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | STX | 4.6L | V8 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| 2009 | Ford | F-150 | XL | 4.2L | V6 | Front | w/ Heavy Payload Package - w/ 7 stud; Wheel Hub Assembly; Axle Nut Torque Spec: 20 ft-lbs / 27Nm, use new axle nut. |
| No rows match your filter. | |||||||
Directly replaces or cross-references 1 part number
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
9L3Z-1104-C
