MPA Electrical WH515183 Wheel Bearing and Hub Assembly - Front
| Brand | MPA Electrical WH515183 |
|---|---|
| Position | Front |
| Flange Bolt Hole Quantity | 4 |
| Hub Pilot Diameter | 5.514 |
| Flange Shape | Square |
| Flange Offset | 1.82 |
| Bolt Circle Diameter | 6.686 |
| Flange Diameter Inch | 8.005 |
| Hub Pilot Diameter Inch | 5.514 |
| Material | Steel |
| Product Condition | New |
| Fits | Ford · 12 vehicles |
OE replacement. Direct-fit wheel hub assembly for professional service work.
Installation ready. Built as a complete unit to reduce prep time in the bay.
Steel construction. Durable hub body with a square flange design.
Cross-references HC3Z 1104-C for the same application. See all 1.
OE Replacement Wheel Hub Assembly
The MPA Electrical WH515183 wheel bearing and hub assembly is an OE replacement for front service on select Ford Super Duty trucks. It is built as an installation-ready unit to help restore safe vehicle operation without extra assembly work.
- OE replacement wheel hub assembly for direct service use.
- Installation-ready design with components included in the assembly.
- Steel construction for durable hub support.
- Square flange shape with a 4-bolt flange pattern.
- Fits Ford F-250 Super Duty and Ford F-350 Super Duty front applications.
Fitment and Application Details
Compatible with 2017-2022 Ford F-250 Super Duty, front, and 2017-2022 Ford F-350 Super Duty, front. The WH515183 is a practical choice when replacing a worn wheel bearing and hub assembly on these Ford Super Duty models. This part cross-references Ford HC3Z 1104-C for the same application.
Key dimensions include a 5.514-inch hub pilot diameter, 8.005-inch flange diameter, 1.82-inch flange offset, and a 6.686-inch bolt circle diameter. These specifications help confirm proper hub geometry for the intended front axle application on Ford F-250 Super Duty and Ford F-350 Super Duty trucks.
What It Helps Resolve
- Wheel bearing noise from a worn hub assembly.
- Excessive hub play or looseness at the wheel.
- Uneven wheel support caused by hub wear.
- Front-end vibration related to hub condition.
- Service delays from a non-ready replacement part.
Installation Notes and Quality
Verify flange bolt hole count, bolt circle diameter, hub pilot diameter, and flange offset before installation. Confirm fitment by vehicle year, make, model, and front position to ensure the correct application. MPA Electrical supplies this as a new, OE replacement wheel hub assembly built for professional installation standards.
WH515183 is listed for 2017-2022 Ford F-250 Super Duty and 2017-2022 Ford F-350 Super Duty front applications.
| Year | Make | Model | Drive Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2022 | Ford | F-250 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2022 | Ford | F-350 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2021 | Ford | F-250 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2021 | Ford | F-350 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2020 | Ford | F-250 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2020 | Ford | F-350 Super Duty | 4WD | 7.3L | V8 | Front | — |
| 2019 | Ford | F-250 Super Duty | 4WD | 6.7L | V8 | Front | — |
| 2019 | Ford | F-350 Super Duty | 4WD | 6.7L | V8 | Front | — |
| 2018 | Ford | F-250 Super Duty | 4WD | 6.7L | V8 | Front | — |
| 2018 | Ford | F-350 Super Duty | 4WD | 6.7L | V8 | Front | — |
| 2017 | Ford | F-250 Super Duty | 4WD | 6.7L | V8 | Front | — |
| 2017 | Ford | F-350 Super Duty | 4WD | 6.7L | V8 | Front | — |
