MPA Electrical WH590139 Wheel Bearing and Hub Assembly - Front Right
| Brand | MPA Electrical WH590139 |
|---|---|
| Position | Front Right |
| Spline Quantity | 30 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Flange Shape | Trapezoid |
| Anti Lock Braking System Type | Encoder |
| Anti Lock Brake Sensor Included | No |
| Flange Offset | 1.97 |
| Flange Diameter | 5.503 |
| Flange Diameter Inch | 5.503 |
| Gasket or Seal Included | Yes |
| Greaseable | No |
| Hub Pilot Diameter Inch | 3.54 |
| Material | Steel |
| Product Condition | New |
| Spline Quantity | 30 |
| Stud Quantity | 5 |
| Wheel Stud Size MM | M12 x 1.5 |
| Wiring Harness Included | No |
| Fits | Lexus · 49 vehicles |
OE-style replacement. Direct-fit wheel bearing and hub assembly for select Lexus applications.
Encoder ABS design. Built with integrated encoder-style braking system compatibility.
Steel hub construction. Includes flange and seal for a complete hub assembly build.
Cross-references 43550-30030 for the same application. See all 1.
$112.20Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Wheel Bearing and Hub Assembly options
Wheel Bearing Hub Assembly Overview
MPA Electrical WH590139 is a new wheel bearing and hub assembly built for front right applications with encoder-style ABS integration. It is a direct-fit replacement for select Lexus models and uses a steel hub design with a flange, seal, and 5-lug mounting pattern.
Key Features
- New wheel bearing and hub assembly for front right service.
- Encoder-type ABS configuration with no sensor included.
- Steel construction with flange included and gasket or seal included.
- 30-spline hub design with M12 x 1.5 wheel studs.
- 5-bolt flange layout and trapezoid flange shape.
Fitment Details
Compatible with Lexus GS350, IS300, IS350, RC300, RC350, IS250, and GS300 front right applications. Fits 2013-2019 Lexus GS350, front right. Fits 2016-2019 Lexus IS300, front right. Fits 2012-2019 Lexus IS350, front right. Fits 2016-2019 Lexus RC300, front right. Fits 2015-2019 Lexus RC350, front right. Fits 2012-2015 Lexus IS250, front right. Fits 2007-2011 Lexus GS350, front right. Fits 2006-2011 Lexus IS250, front right. Fits 2011 Lexus IS350, front right. Fits 2006 Lexus GS300, front right.
This part cross-references Toyota/Lexus OE number 43550-30030 for the same application.
What It Helps Address
- Wheel bearing noise or rough rotation at the hub.
- ABS signal issues related to encoder-style hub operation.
- Loose or worn hub mounting surfaces.
- Stud or flange wear on the wheel-end assembly.
Installation Notes
Confirm axle nut torque using the OE service manual for the specific Lexus application. Verify spline count, stud pattern, and ABS encoder style before installation.
Quality Assurance
MPA Electrical identifies this as a Quality-Built Hubs & Bearings product line component. Part number WH590139 is supplied as a new assembly.
This part fits 49 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
| Year | Make | Model | Drive Type | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2019 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | IS300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | IS300 | AWD | 2.0L | L4 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | RC300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | RC300 | AWD | 2.0L | L4 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Lexus | RC350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | IS300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | IS300 | AWD | 2.0L | L4 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | RC300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | RC300 | AWD | 2.0L | L4 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Lexus | RC350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Lexus | IS300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Lexus | RC300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Lexus | RC350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lexus | IS300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lexus | RC300 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lexus | RC350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lexus | RC350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2012 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2012 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2011 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2011 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2011 | Lexus | IS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2010 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2010 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2009 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2009 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2008 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2008 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2007 | Lexus | GS350 | AWD | 3.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2007 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2006 | Lexus | GS300 | AWD | 3.0L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| 2006 | Lexus | IS250 | AWD | 2.5L | V6 | Front Right | Wheel Hub Assembly; Axle Nut Torque Spec: 217 ft-lbs / 294Nm |
| No rows match your filter. | |||||||
Directly replaces or cross-references 1 part number
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
43550-30030
