OE Quality
60-Day Returns
MPA Electrical WH590481 Wheel Bearing and Hub Assembly - Front or Rear
| Brand | MPA Electrical WH590481 |
|---|---|
| Position | Front and Rear |
| Spline Quantity | 27 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Flange Shape | Modified rectangle |
| Anti Lock Braking System Type | Encoder |
| Anti Lock Brake Sensor Included | No |
| Flange Offset | 1.89 |
| Flange Diameter | 5.345 |
| Flange Diameter Inch | 5.345 |
| Gasket or Seal Included | Yes |
| Greaseable | No |
| Hub Pilot Diameter Inch | 3.15 |
| Material | Steel |
| Product Condition | New |
| Spline Quantity | 27 |
| Stud Quantity | 5 |
| Wheel Stud Size MM | M12 x 1.5 |
| Wiring Harness Included | No |
| Fits | Ford and Lincoln · 65 vehicles |
OE-style replacement. New hub and bearing assembly for direct service replacement.
Encoder ABS design. Supports hub-integrated wheel speed signal applications.
Steel construction. Built with an included flange and seal for service work.
Cross-references DG9Z 1104-E, DG9Z1104A and DG9Z1104B for the same application. See all 4.
$130.68Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Wheel Bearing and Hub Assembly options
Wheel Bearing and Hub Assembly Overview
MPA Electrical WH590481 is a new wheel bearing and hub assembly built for Ford and Lincoln applications that require an encoder-style ABS hub. It combines the hub, bearing, flange, and seal into one service part for direct replacement use on select Fusion and MKZ models.
Key Features
- Steel hub and bearing construction for service replacement durability.
- Encoder-type ABS design for vehicles that use a hub-integrated wheel speed signal.
- Flange included with a modified rectangle shape and five wheel studs.
- 27-spline design with M12 x 1.5 wheel studs.
- Seal included for a complete hub assembly service part.
Fitment Details
Compatible With select Ford Fusion and Lincoln MKZ applications. Fits 2020 Ford Fusion, front. Fits 2019-2020 Ford Police Responder Hybrid, front. Fits 2019-2020 Ford SSV Plug-In Hybrid, front. Fits 2013-2019 Ford Fusion, front and rear. Fits 2013-2016 Lincoln MKZ, front. Fits 2013-2015 Lincoln MKZ, rear. This part cross-references Ford OE numbers DG9Z 1104-E and DG9Z1104A for the same application.
Common Replacement Uses
- Wheel bearing noise or rough hub rotation.
- ABS warning concerns related to the hub encoder signal.
- Loose, worn, or damaged hub flange service needs.
- Wheel stud or hub assembly replacement on supported Ford Fusion and Lincoln MKZ models.
Installation Notes
Verify axle nut torque using the OE service manual for the specific application. Confirm the vehicle uses the correct 12 mm wheel lug stud specification before installation. Match the ABS encoder style and fitment position to the original hub assembly.
Quality Assurance
MPA Electrical identifies this part as a Quality-Built hub and bearing assembly. Part number WH590481 is supplied as a new replacement component for service work on the listed Ford and Lincoln vehicles.
This part fits 65 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
| Year | Make | Model | Drive Type | Liters | Cylinders | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|---|---|
| 2020 | Ford | Fusion | — | 2.5L | L4 | — | Front | — |
| 2020 | Ford | Police Responder Hybrid | — | — | — | — | Front | — |
| 2020 | Ford | SSV Plug-In Hybrid | — | — | — | — | Front | — |
| 2019 | Ford | Fusion | — | 2.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | AWD | 2.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Fusion | AWD | 1.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2019 | Ford | Police Responder Hybrid | — | — | — | — | Front | — |
| 2019 | Ford | SSV Plug-In Hybrid | — | — | — | — | Front | — |
| 2018 | Ford | Fusion | — | 2.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | AWD | 2.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2018 | Ford | Fusion | AWD | 1.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | — | 2.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | AWD | 2.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2017 | Ford | Fusion | AWD | 1.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Ford | Fusion | AWD | 1.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2016 | Lincoln | MKZ | — | 2.0L | L4 | ELECTRIC/GAS | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Ford | Fusion | AWD | 1.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lincoln | MKZ | — | 3.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lincoln | MKZ | AWD | 3.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lincoln | MKZ | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2015 | Lincoln | MKZ | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Ford | Fusion | — | 1.6L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Ford | Fusion | — | 1.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lincoln | MKZ | — | 3.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lincoln | MKZ | AWD | 3.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lincoln | MKZ | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2014 | Lincoln | MKZ | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | — | 2.5L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | AWD | 2.5L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | — | 1.6L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Ford | Fusion | AWD | 1.6L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lincoln | MKZ | — | 3.7L | V6 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lincoln | MKZ | AWD | 3.7L | V6 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lincoln | MKZ | — | 2.0L | L4 | — | Front | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| 2013 | Lincoln | MKZ | AWD | 2.0L | L4 | — | Rear | 12mm Wheel Lug Stud; Wheel Hub Assembly; Axle Nut Torque Spec: Refer to OE service manual |
| No rows match your filter. | ||||||||
Directly replaces or cross-references 4 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
DG9Z 1104-EDG9Z1104ADG9Z1104BDG9Z1104D
