Nugeon 99P01764A Disc Brake Caliper - Rear Right

Overview

This Nugeon disc brake caliper is built for rear right applications and follows the TechShield 360 line. Part number 99P01764A is a direct-fit brake hydraulic replacement for select Toyota models with the specified rear brake setup.

It features an aluminum caliper body, steel piston, E-coat finish, and included bracket, slides, bleeder screw, dust boots, and caliper-and-pad hardware. Part number 99P01764A is listed with the Tokico caliper manufacturer reference and uses a banjo bolt inlet connection.

Key Features

• Aluminum caliper casting with gray E-coat finish for corrosion resistance.
• Single 38 mm steel piston for rear brake actuation.
• Bracket, caliper slides, bleeder screw, and dust boots included.
• Banjo bolt inlet with M10-1.0 thread specification.
• Fits rear right brake service on select Toyota Corolla, Prius, Prius AWD-e, and Prius Prime applications.

Fitment Details

Compatible with Fits 2020-2025 Toyota Corolla, rear right, with manual parking brake and TechShield 360 (tm). Fits 2016-2022 Toyota Prius, rear right, supplied with mounting bracket and TechShield 360 (tm). Fits 2019-2022 Toyota Prius AWD-e, rear right, supplied with mounting bracket and TechShield 360 (tm). Fits 2017-2022 Toyota Prius Prime, rear right, supplied with mounting bracket and TechShield 360 (tm).

This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Common Repair Uses

• Restores rear brake hydraulic function when the caliper is sticking or leaking.
• Addresses uneven rear braking caused by worn piston or slide components.
• Replaces a damaged caliper bracket or housing on the rear right side.
• Helps correct brake drag, noise, or poor pedal response linked to caliper wear.

Installation Notes

Verify the rear right fitment, brake configuration, and inlet thread before installation. Transfer or replace brake pads as needed, and bleed the hydraulic system after installation. Confirm the banjo bolt and copper crush washer arrangement matches the vehicle application.

Quality Assurance

Nugeon TechShield 360 calipers are built as application-specific brake hydraulic replacements with OE-style mounting and component details. Part number 99P01764A is identified with Tokico caliper references for the listed applications.
