Pagid 355034551 Disc Brake Pad Set - Front

Pagid NAO-Range Front Brake Pads

Pagid 355034551 is a front disc brake pad set built for standard replacement service on select Geo, Isuzu, and Mazda applications. It uses a ceramic friction material and includes adhesive-backed pad shims plus abutment clips for the listed fitments.

The NAO-Range line focuses on everyday braking performance with OE-style fitment details for vehicles such as the Mazda Miata, Geo Storm, and Isuzu Impulse. Part number 355034551 is matched to Sumitomo brake systems and the listed front applications below.

Key Features

• Ceramic friction material for standard replacement use
• Front disc brake pad set for Sumitomo brake systems
• Adhesive-backed pad shim included
• Abutment clips included
• Pad wear sensor not included
• Not prepared for wear indicator contact
• FMSI number D525-7337 and WVA number 21552
• Part number 355034551

Detailed Description

Pagid NAO-Range 355034551 is a ceramic front brake pad set with a pad thickness of 14.4 mm, inner and outer pad height of 46.1 mm, and width of 110.6 mm. It is specified for Sumitomo brake systems and listed for 1990-1993 Geo Storm front, 1991-1993 Isuzu Stylus front, 1990-1993 Mazda Miata front, and 1990-1992 Isuzu Impulse front. This part cross-references Centric Parts 105.05250 for the same application.

Common Issues This Part Addresses

• Worn front brake pads that reduce stopping performance
• Brake noise caused by aged pad friction material
• Uneven pad contact from deteriorated pad shims
• Loss of braking consistency during normal street driving
• Need for a direct replacement pad set for Sumitomo-equipped front brakes

Installation Notes and Tips

Confirm rotor condition, caliper hardware condition, and brake system compatibility before installation. Clean the caliper abutment areas, install the included clips, and follow the vehicle service procedure for pad bedding after replacement. Verify the pad dimensions and FMSI D525-7337 match the removed pads before installation on your Mazda Miata, Geo Storm, or Isuzu application.

Quality Assurance

Pagid NAO-Range brake components are built as standard replacement parts with OE-style fitment references and published dimensional data for accurate application matching. Use the listed part number 355034551 and vehicle fitment details to confirm the correct front brake pad set for the application.
