Pagid 355122541 Disc Brake Rotor - Front

Overview of Pagid Disc Brake Rotor 355122541

The Pagid disc brake rotor 355122541 is engineered for reliable braking performance on select Mercedes-Benz models. Designed with durability and corrosion resistance in mind, this rotor suits vehicles such as the GLE300d, GLE350, GLE400, ML250, ML350, and ML400.

• Material: Gray cast iron for strength and heat dissipation
• Nominal thickness: 32.00 mm with discard thickness at 29.40 mm
• Coated disc and hat finish for rust resistance
• Vented full cast construction to improve cooling
• X-drilled surface type for enhanced brake pad contact
• Eight bolt holes for secure fitment
• Outside diameter of 350.00 mm and height of 54.40 mm

Hella Pagid - High Carbon and Fully Coated Product Line

This rotor is part of the Hella Pagid - High Carbon and Fully Coated line, which focuses on combining high carbon content with a full coating process. This approach improves rotor durability and corrosion resistance, extending service life while maintaining consistent braking performance. The fully coated finish protects both the disc and hat areas, making it suitable for demanding driving conditions.

Detailed Product Description

The Pagid 355122541 disc brake rotor is constructed from gray cast iron, a material known for its excellent thermal conductivity and wear resistance. Its vented design allows air to flow between the rotor surfaces, reducing heat buildup during braking. The X-drilled surface enhances pad bite and helps dissipate gases and debris, contributing to consistent braking feel. Both the disc and hat are coated to resist rust, which is critical for maintaining rotor integrity over time. With an outside diameter of 350 mm and a height of 54.40 mm, this rotor is engineered to meet the specifications required by Mercedes-Benz GLE and ML series models.

Compatible Vehicles and Common Applications

• Replacement rotor for Mercedes-Benz GLE300d, GLE350, and GLE400
• Suitable for Mercedes-Benz ML250, ML350, and ML400 models
• Addresses issues such as brake rotor warping and uneven wear
• Helps resolve brake noise caused by surface irregularities
• Improves braking consistency and pedal feel

Installation Notes and Tips

Ensure the rotor thickness is within the specified discard limit of 29.40 mm before installation. Proper cleaning of the hub surface and rotor mounting area is recommended to prevent runout. Use the correct torque specifications for the eight bolt holes to secure the rotor firmly. It is advisable to inspect brake pads and hardware during rotor replacement to maintain optimal braking system performance.

Quality Assurance and Warranty

Pagid rotors are manufactured to meet OEM standards for fit, form, and function. The rust-resistant coating and high carbon content contribute to long service life and reliable braking. While specific warranty details are not provided, Pagid products typically adhere to industry quality controls to ensure consistent performance on Mercedes-Benz GLE and ML series vehicles.
