Pagid 355797482 Disc Brake Caliper - Rear Right
| Brand | Pagid 355797482 |
|---|---|
| Position | Rear Right |
| Pad Wear Sensor Included | No |
| Mounting Hardware Included | Yes |
| Grade Type | Standard replacement |
| Caliper Casting Material | Cast iron |
| Mounting Bolt Included | Yes |
| Bleeder Screw Included | Yes |
| Anti-Rattle Spring Included | No |
| Caliper Slides Included | Yes |
| Piston Quantity | 1 |
| Caliper Type | Floating |
| Piston Diameter | 86.00 |
| Caliper Color | Gray |
| Abutment Clips Included | No |
| Mounting Bracket Included | No |
| Piston Material | Steel |
| Bleeder Screw Thread Size | M10 - 1.0 |
| Bleeder Screw Quantity | 1 |
| Caliper Finish | Powder coated |
| Bleeder Screw Thread Diameter [mm] | 8.5 |
| Bleeder Screw Thread Pitch [mm] | 1.5 |
| Bleeder Screw Thread Size | M10x1.5-6h |
| Inlet Thread Diameter [mm] | 8.5 |
| Inlet Thread Pitch [mm] | 1.5 |
| Fits | Audi · 7 vehicles |
OE-standard testing. Built to meet OE-level braking requirements for the specified application.
Floating caliper design. Uses a single-piston layout for consistent hydraulic operation.
Service-ready hardware. Includes bleeder screw, slides, and mounting bolt for replacement work.
Cross-references 8K0 615 404 and 8K0 615 404A for the same application. See all 2.
Product Overview
This Pagid disc brake caliper is a standard replacement unit built for precise brake system requirements and OE-level performance expectations. It fits Audi S4 and Audi S5 rear right applications with parking brake actuator integration, and the part number is 355797482.
Designed as a floating caliper with a cast iron body and steel piston, this caliper uses a powder-coated gray finish for added surface protection. The included bleeder screw, caliper slides, and mounting bolt support a complete service replacement for the specified application.
Key Features
- Standard replacement disc brake caliper for brake hydraulic service
- Floating caliper design with one 86.00 mm piston
- Cast iron caliper housing with steel piston construction
- Powder-coated gray finish for corrosion resistance
- Bleeder screw, caliper slides, and mounting bolt included
- Fits rear right Audi S4 and Audi S5 applications with parking brake actuator
Detailed Description
Pagid 355797482 is engineered for European vehicle brake systems that require consistent hydraulic response and OE-standard fitment. This caliper is built for rear right installation on 2010-2012 Audi S4 and 2010-2012 Audi S5, plus 2008 Audi S5 applications, all with parking brake actuator provisions. The floating design, cast iron body, and steel piston support stable braking performance under everyday driving loads.
HELLA brake calipers are developed to meet the demands of different vehicle platforms and braking characteristics, with testing performed to OE standards. This part cross-references Audi part numbers 8K0 615 404 and 8K0 615 404A for the same application. The part number 355797482 is useful when matching the correct rear brake caliper for these Audi models.
What It Helps Solve
- Brake fluid leakage from a worn caliper body or piston seal area
- Uneven rear braking caused by a sticking or seized caliper
- Poor parking brake actuator function at the rear brake assembly
- Corrosion-related caliper movement issues on the brake slides
- Brake drag or inconsistent pedal response from a failing hydraulic caliper
Installation Notes
Fits 2010-2012 Audi S4, rear right. Fits 2010-2012 Audi S5, rear right. Fits 2008 Audi S5, rear right. Verify the parking brake actuator configuration and brake line thread specifications before installation. The caliper includes a bleeder screw and caliper slides; mounting bracket and pad wear sensor are not included.
Quality Assurance
Pagid brake calipers are manufactured to OE standards and tested for compliance with the braking requirements of the intended application. Part number 355797482 is built for the specified Audi fitment and brake system configuration.
| Year | Make | Model | Submodel | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2012 | Audi | S4 | Base | 3.0L | V6 | Rear Right | Incl.Parking Brake Actuator |
| 2012 | Audi | S5 | Base | 4.2L | V8 | Rear Right | Incl.Parking Brake Actuator |
| 2011 | Audi | S4 | Base | 3.0L | V6 | Rear Right | Incl.Parking Brake Actuator |
| 2011 | Audi | S5 | Base | — | — | Rear Right | Incl.Parking Brake Actuator |
| 2010 | Audi | S4 | Base | 3.0L | V6 | Rear Right | Incl.Parking Brake Actuator |
| 2010 | Audi | S5 | Base | — | — | Rear Right | Incl.Parking Brake Actuator |
| 2008 | Audi | S5 | Base | — | — | Rear Right | Incl.Parking Brake Actuator |
