PowerStop AR8569 Disc Brake Rotor - Front or Rear

OE Stock Replacement Rotor

Power Stop AR8569 is a direct-fit disc brake rotor built for original equipment fit and performance. It is a vented rotor with a 15.50-inch outside diameter, 1.50-inch nominal thickness, and a 10-lug bolt pattern for heavy-duty Ford applications.

Compatible with Ford F-53 Motorhome Chassis, Ford F-59 Commercial Stripped Chassis, Ford F-450 Super Duty, Ford F-550 Super Duty, and Ford E-550 Super Duty applications listed below, this rotor is sized for specific front and rear brake setups. The Power Stop OE Stock Replacement Brake Rotor line focuses on straightforward replacement fitment for service work where matching OE dimensions matters.

• Fits 2016-2019 Ford F-53 Motorhome Chassis, front, to 23,000 lb GVW.
• Fits 2016-2019 Ford F-53 Motorhome Chassis, rear, 16,000 to 18,000 lb GVW.
• Fits 2015-2019 Ford F-59 Commercial Stripped Chassis, front.
• Fits 2015-2019 Ford F-59 Commercial Stripped Chassis, rear, 16,000 to 19,500 lb GVW.
• Fits 2011-2015 Ford F-53 Motorhome Chassis, front, under 23,000 lb GVW; Dana 80, 110, 130 rear axles.
• Fits 2008-2009 Ford F-53 Motorhome Chassis, front, under 23,000 lb GVW; Dana 80, 110, 130 rear axles.
• Fits 2006-2007 Ford F-53 Motorhome Chassis, front.
• Fits 1999-2004 Ford F-53 Motorhome Chassis, front.
• Fits 2002-2004 Ford F-450 Super Duty, rear, without ABS ring.
• Fits 2002-2004 Ford F-550 Super Duty, rear, no ABS ring.
• Fits 2003 Ford E-550 Super Duty, rear.
• Fits 2002 Ford E-550 Econoline Super Duty, rear.
• Fits 1999-2001 Ford F-450 Super Duty, rear.
• Fits 1999-2001 Ford F-550 Super Duty, rear.
• Fits 1999-2000 Ford F-53 Motorhome Chassis, rear.

Key Features

• Direct-fit replacement rotor for OE-style service.
• Vented design for brake heat management.
• Heavy-duty dimensions for select Ford chassis and Super Duty applications.
• 10-lug mounting pattern for listed fitments.

What It Helps Address

• Rotor wear that calls for replacement.
• Brake pulsation caused by a worn or out-of-spec rotor.
• Heat buildup in demanding chassis braking use.
• Fitment issues when the original rotor dimensions must be matched exactly.

Installation Notes

Verify axle, GVW, and ABS-ring requirements before ordering, since fitment varies by chassis configuration. Confirm the rotor dimensions and bolt pattern against the removed part before installation. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.

Quality Assurance

Power Stop positions the Autospecialty line as an OE-style replacement range focused on original equipment fit and performance. Part number AR8569 is built to match the listed applications for service replacement on Ford heavy-duty chassis platforms.
