Raybestos 580264FZN Disc Brake Rotor - Front

Reliable Disc Brake Rotor for Cadillac and Pontiac Vehicles

The Raybestos Element3; Coated Rotor 580264FZN is engineered to provide consistent braking performance for select Cadillac and Pontiac models. Designed as a solid, conventional disc brake rotor, it meets precise specifications to ensure proper fit and function.

• Compatible with Cadillac CTS, STS, and Pontiac Bonneville
• Solid rotor design with 5 mounting bolt holes
• Nominal thickness of 1.270 inches (32.250 mm) and discard thickness of 1.209 inches (30.700 mm)
• Overall height of 2.040 inches (51.800 mm) and outside diameter of 12.715 inches (322.950 mm)
• Center hole diameter of 2.783 inches (70.700 mm) and mounting bolt hole circle diameter of 4.528 inches (115.000 mm)

Product Line: Raybestos Element3; Coated Rotor

The Element3; Coated Rotor line from Raybestos features a protective coating designed to resist corrosion and extend rotor life. This coating helps maintain rotor integrity and appearance over time, making it suitable for vehicles like the Cadillac CTS and Pontiac Bonneville that require reliable braking components. The 580264FZN part number represents a solid rotor variant within this line, optimized for conventional mounting and consistent thickness specifications.

Technical Specifications and Features

This disc brake rotor is a solid type, providing a stable braking surface without venting. It includes five mounting bolt holes and five stud/lug holes, ensuring secure attachment to the hub. The rotor’s nominal thickness is 1.270 inches (32.250 mm), with a discard thickness of 1.209 inches (30.700 mm), indicating when replacement is necessary to maintain safe braking performance. The overall height measures 2.040 inches (51.800 mm), and the outside diameter is 12.715 inches (322.950 mm), matching factory specifications for the compatible Cadillac and Pontiac models.

Common Applications and Problem Solving

• Replacement for worn or warped rotors on Cadillac CTS, STS, and Pontiac Bonneville
• Addresses brake pulsation caused by uneven rotor thickness
• Resolves noise issues related to rotor surface imperfections
• Prevents corrosion-related rotor degradation with coated surface
• Ensures proper rotor thickness for safe braking performance

Installation Notes and Tips

When installing the Raybestos 580264FZN rotor, ensure the mounting surface is clean and free of debris. Verify the rotor thickness before installation to confirm it meets nominal specifications. Use proper torque settings on the five mounting bolts to avoid rotor distortion. It is recommended to replace brake pads simultaneously to optimize braking efficiency and rotor lifespan.

Quality Assurance and Warranty

Raybestos disc brake rotors undergo rigorous quality control to meet industry standards for durability and performance. The Element3; Coated Rotor line includes corrosion-resistant coatings to enhance longevity. Warranty coverage details should be confirmed with the manufacturer or authorized distributor to ensure compliance with specific vehicle requirements.
