Raybestos 96586R Disc Brake Rotor - Front

Overview of Raybestos R-Line Disc Brake Rotor 96586R

The Raybestos R-Line Disc Brake Rotor 96586R is engineered for reliable braking performance on select Jaguar models. Designed specifically for Jaguar Vanden Plas, XJ6, XJ12, and XJR vehicles, this vented rotor meets precise specifications to maintain optimal stopping power and durability.

• Part Number: 96586R
• Brand: Raybestos R-Line
• Type: Vented Disc Brake Rotor
• Outside Diameter: 11.460 inches (291.1 mm)
• Nominal Thickness: 1.110 inches (28.2 mm)
• Discard Thickness: 1.063 inches (27.0 mm)
• Overall Height: 2.635 inches (66.95 mm)
• Mounting Bolt Hole Quantity: 5
• Center Hole Diameter: 3.150 inches (80.0 mm)
• Mounting Bolt Hole Circle Diameter: 4.750 inches (120.65 mm)
• Stud/Lug Hole Quantity: 5
• Conventional Rotor Type

Detailed Product Description

The Raybestos R-Line 96586R disc brake rotor is a vented, conventional rotor designed to provide consistent heat dissipation and braking efficiency. With an outside diameter of 11.460 inches and a nominal thickness of 1.110 inches, this rotor is engineered to meet the exacting standards required for Jaguar Vanden Plas, XJ6, XJ12, and XJR models. The vented design helps reduce brake fade by allowing air to circulate between the rotor surfaces, maintaining cooler operating temperatures during braking. The rotor features five mounting bolt holes and a center hole diameter of 3.150 inches, ensuring proper fitment and secure installation on compatible Jaguar vehicles.

Raybestos R-Line Product Line Information

The R-Line by Raybestos is a product line focused on delivering reliable, OE-quality brake components for a range of vehicles. This line emphasizes precision manufacturing and material quality to provide rotors that meet or exceed original equipment specifications. The 96586R rotor exemplifies the R-Line’s commitment to durability and consistent braking performance, making it suitable for Jaguar models requiring exact fit and function.

Applications and Problem Solving

• Compatible with Jaguar Vanden Plas, XJ6, XJ12, and XJR models
• Addresses rotor wear and thickness below discard limits
• Helps reduce brake fade caused by overheating
• Resolves issues related to uneven rotor surface or warping
• Restores proper braking performance and pedal feel

Installation Notes and Tips

• Verify rotor thickness before installation; discard thickness is 1.063 inches
• Ensure mounting surfaces and bolt holes are clean and free of debris
• Torque mounting bolts to manufacturer specifications for secure fitment
• Inspect brake pads and replace if worn to ensure optimal rotor performance
• Perform a brake system test after installation to confirm proper operation

Quality Assurance and Warranty

Raybestos R-Line rotors are manufactured to meet stringent quality standards, ensuring consistent performance and durability. While specific warranty details for part number 96586R are not provided here, Raybestos typically offers limited warranties covering defects in materials and workmanship. Users should consult product documentation or Raybestos directly for warranty terms applicable to this rotor.
