Raybestos 96807R Disc Brake Rotor - Front

Overview of Raybestos R-Line Disc Brake Rotor 96807R

The Raybestos R-Line Disc Brake Rotor 96807R is engineered for reliable braking performance on Mitsubishi Galant and Lancer models. Designed as a vented, conventional rotor, it offers effective heat dissipation and consistent stopping power for these vehicles.

• Compatible with Mitsubishi Galant and Lancer
• Vented disc brake rotor design for improved cooling
• Overall height: 1.780 inches (45.200 mm)
• Outside diameter: 10.080 inches (256.050 mm)
• Mounting bolt hole quantity: 4 with 114.3 mm bolt circle diameter
• Center hole diameter: 2.717 inches (69.000 mm)
• Nominal thickness: 0.945 inches (24.000 mm)
• Discard thickness: 0.882 inches (22.400 mm)
• Conventional rotor type with 4 stud/lug holes

Raybestos R-Line Product Line Details

The R-Line by Raybestos focuses on delivering dependable brake components that meet or exceed OEM specifications. This product line emphasizes durability and consistent performance, making it suitable for daily driving conditions on vehicles like the Mitsubishi Galant and Lancer. The 96807R rotor is part of this line, providing a balance of quality and fitment precision.

Technical Specifications and Features

This disc brake rotor features a vented design that enhances heat dissipation during braking, reducing the risk of brake fade. The overall height of 1.780 inches and outside diameter of 10.080 inches ensure proper fitment and compatibility with the specified Mitsubishi models. The rotor includes four mounting bolt holes arranged on a 114.3 mm bolt circle diameter, matching the vehicle’s hub assembly. With a nominal thickness of 0.945 inches and a discard thickness of 0.882 inches, this rotor maintains structural integrity and safety standards throughout its service life.

Common Applications and Problem Resolution

• Replacement for worn or warped rotors on Mitsubishi Galant and Lancer
• Addresses brake noise and vibration issues caused by uneven rotor surfaces
• Improves braking performance by restoring proper rotor thickness
• Helps prevent brake fade through vented rotor design
• Suitable for routine maintenance and brake system repairs

Installation Notes and Tips

Ensure the rotor surface and hub are clean and free of debris before installation. Verify the mounting bolt hole alignment with the vehicle’s hub assembly. Use a calibrated torque wrench to tighten bolts to manufacturer specifications. It is recommended to replace brake pads simultaneously to maintain optimal braking performance. Check rotor thickness regularly and replace when below discard thickness of 0.882 inches.

Quality Assurance and Warranty

Raybestos R-Line rotors are manufactured to meet OEM standards for fit, form, and function. The 96807R rotor undergoes rigorous quality control to ensure durability and consistent braking performance. Warranty coverage details should be confirmed with the product documentation or supplier, as they may vary.
