Raybestos BC93478 Parking Brake Cable - Rear Right
| Brand | Raybestos 56316 |
|---|---|
| Bracket? | w/o Bracket |
| Component Type | Suction Line |
| Description | Hose Assemblies |
| End 1 Type | P-Nut Fitting |
| End 2 Type | Female O-Ring |
| Fittings Included | Included |
| Friction Material Attachment | w/o Switch Port |
| Gasket Or Seal Included | Included |
| Material | Aluminum / Rubber |
| Muffler? | w/o Muffler |
| O-Ring A Number/Desc | [24150] / Black O-Ring |
| O.E. Replacement? | Yes |
| Refrigerant Type | R134-A |
| Service Port Qty | 1 |
| Service Port Size | 13 mm |
| Service Port Type | R134-A Quick Disconnect |
| Service Port? | w/ Service Port |
| Suction End Type | Female O-Ring |
| Sve Port Low Side | Low Side |
| Switch Included? | Not Included |
| System Pressure | Low Pressure |
| Product line | Element3 |
| Fits | —28 vehicles |
Barrel ends. Both cable ends use barrel fittings for secure attachment.
Parking brake cable. Built for dependable brake system operation and control.
Element3 line. Part of Raybestos' premium brake component family.
Cross-references AMS Automotive 6462, AMS Automotive 6900 and Anchor 3528 for the same application. See all 21.
Raybestos Element3 BC93478 Parking Brake Cable
Raybestos Element3 BC93478 is a rear right parking brake cable built for specific GM applications from the mid-to-late 1980s. It uses barrel fittings at both ends and the listed cable and housing dimensions to support a direct-fit replacement for the original parking brake linkage.
Key Features
- Parking brake cable for the rear right position
- Barrel fitting type at end 1 and end 2
- Cable diameter: 0.125 in.
- Overall cable length: 34.000 in. / 86.360 cm
- Overall housing length: 23.812 in. / 60.480 cm
- Raybestos Element3 line for brake service applications
- Cross-reference: Dorman - First Stop C93478
Detailed Description
BC93478 is a Raybestos parking brake cable for rear right applications on 1985-1989 Cadillac DeVille, 1985-1989 Cadillac Fleetwood, 1985-1989 Oldsmobile 98, 1986-1989 Buick LeSabre, 1986-1989 Oldsmobile Delta 88, and 1987-1989 Pontiac Bonneville. The cable’s 0.125-inch diameter, barrel-style end fittings, and specified housing and overall lengths help match the original routing and connection points used on these vehicles. If you are replacing a worn parking brake cable on a Cadillac DeVille or Buick LeSabre, BC93478 provides the fitment and dimensions needed for the rear right side.
Raybestos Element3 is the brand line used for brake components that focus on application-specific fitment and service-ready dimensions. For shoppers searching for a parking brake cable for 1985-1989 Cadillac Fleetwood rear right or 1986-1989 Oldsmobile Delta 88 rear right, BC93478 is the part number to reference.
What It Helps Fix
- Broken or frayed parking brake cable
- Parking brake that will not hold the vehicle
- Excessive slack in the rear right cable run
- Corrosion or binding in the existing cable assembly
- Uneven parking brake engagement on the rear right side
Installation Notes
Verify the rear right position, cable length, housing length, and barrel-end configuration before installation. Compare the original routing and attachment points on the vehicle to the listed dimensions for BC93478. Confirm fitment for the exact year, make, and model before service, especially on 1985-1989 Cadillac DeVille, 1985-1989 Cadillac Fleetwood, and 1986-1989 Buick LeSabre applications.
Quality Assurance
Raybestos Element3 brake parts are cataloged by application and dimensional specifications to support accurate replacement selection. This part cross-references Dorman - First Stop C93478 for the same application.
| Year | Make | Model | Submodel | Body Type | # Doors | Position | Notes |
|---|---|---|---|---|---|---|---|
| 1989 | Buick | LeSabre | — | Sedan | 4 Door | Rear Right | Element3 |
| 1989 | Buick | LeSabre | — | Coupe | 2 Door | Rear Right | Element3 |
| 1989 | Cadillac | DeVille | — | — | — | Rear Right | Element3 |
| 1989 | Cadillac | Fleetwood | d'Elegance | — | — | Rear Right | Element3 |
| 1989 | Oldsmobile | 98 | — | — | — | Rear Right | Element3 |
| 1989 | Oldsmobile | Delta 88 | — | — | — | Rear Right | Element3 |
| 1989 | Pontiac | Bonneville | — | — | — | Rear Right | Element3 |
| 1988 | Buick | LeSabre | — | Sedan | 4 Door | Rear Right | Element3 |
| 1988 | Buick | LeSabre | — | Coupe | 2 Door | Rear Right | Element3 |
| 1988 | Cadillac | DeVille | — | — | — | Rear Right | Element3 |
| 1988 | Cadillac | Fleetwood | d'Elegance | — | — | Rear Right | Element3 |
| 1988 | Oldsmobile | 98 | — | — | — | Rear Right | Element3 |
| 1988 | Oldsmobile | Delta 88 | — | — | — | Rear Right | Element3 |
| 1988 | Pontiac | Bonneville | — | — | — | Rear Right | Element3 |
| 1987 | Buick | LeSabre | — | — | — | Rear Right | Element3 |
| 1987 | Cadillac | DeVille | — | — | — | Rear Right | Element3 |
| 1987 | Cadillac | Fleetwood | d'Elegance | — | — | Rear Right | Element3 |
| 1987 | Oldsmobile | 98 | — | — | — | Rear Right | Element3 |
| 1987 | Oldsmobile | Delta 88 | — | — | — | Rear Right | Element3 |
| 1987 | Pontiac | Bonneville | — | — | — | Rear Right | Element3 |
| 1986 | Buick | LeSabre | — | — | — | Rear Right | Element3 |
| 1986 | Cadillac | DeVille | — | — | — | Rear Right | Element3 |
| 1986 | Cadillac | Fleetwood | Base | — | — | Rear Right | Element3 |
| 1986 | Oldsmobile | 98 | — | — | — | Rear Right | Element3 |
| 1986 | Oldsmobile | Delta 88 | — | — | — | Rear Right | Element3 |
| 1985 | Cadillac | DeVille | — | — | — | Rear Right | Element3 |
| 1985 | Cadillac | Fleetwood | Base | — | — | Rear Right | Element3 |
| 1985 | Oldsmobile | 98 | — | — | — | Rear Right | Element3 |
