Raybestos BC96788 Parking Brake Cable - Rear Left
| Brand | Raybestos ALS1187 |
|---|---|
| Connector Gender | Female |
| Connector Shape | Oval |
| Harness Length - inches | 32 |
| Harness Length - mm | 812.8 mm |
| Mounting Location | Spindle |
| Mounting Type | Bolt Mount |
| Number of Bolt Holes | 3 |
| Terminal Gender | Male |
| Terminal Type | Blade |
| Product line | Element3 |
| Fits | —13 vehicles |
Barrel fittings. Both ends use barrel-style fittings for secure cable attachment.
Long cable length. Overall length measures 68.070 inches for broad routing flexibility.
Element3 line. Part of Raybestos' Element3 product line.
Cross-references Carlson 41163, Dorman - First Stop C660477 and 1741163 for the same application. See all 7.
Raybestos Element3 Parking Brake Cable BC96788
Raybestos Element3 BC96788 is a rear left parking brake cable built for specific Chevrolet Silverado 1500 and GMC Sierra 1500 applications. It uses barrel fittings at both ends and the listed cable and housing dimensions to match the original routing and connection points.
Key Features
- Parking brake cable for rear left placement
- Barrel fitting type at End 1 and End 2
- Overall cable length: 172.900 in. (68.070 in.)
- Overall housing length: 136.295 in. (53.660 in.)
- Raybestos Element3 line for application-specific brake hardware
Product Details
The Raybestos Element3 BC96788 parking brake cable is specified for 2006 Chevrolet Silverado 1500 rear left, 2005-2006 GMC Sierra 1500 rear left, and 2005 Chevrolet Silverado 1500 rear left with Vacuum Brake System and 6400lb or 7000lb GVW. This part number is also referenced as BC96788 in brake hardware catalogs, making it easier to verify the correct rear left cable for the truck before ordering.
Element3 is Raybestos’ brake-focused product line for replacement parts that follow vehicle-specific fitment and dimensional requirements. For this application, the cable length and housing length are important because parking brake cables must route correctly and engage the rear brake mechanism without excess slack or binding. This part cross-references Carlson 41163 and Dorman - First Stop C660477 for the same application.
Common Issues This Part Addresses
- Parking brake cable fraying or corrosion
- Sticking or uneven parking brake engagement
- Loss of parking brake tension at the rear left wheel
- Broken or seized cable movement
- Incorrect cable length after prior repair work
Installation Notes
Verify rear left placement, barrel-end configuration, and the listed dimensions against the original cable before installation. Confirm the vehicle’s brake system details, including Vacuum Brake System and GVW notes where applicable, on 2005 Chevrolet Silverado 1500 applications. Inspect cable routing, retaining points, and the parking brake lever and rear brake hardware for wear before final adjustment.
Quality Assurance
Raybestos Element3 brake hardware is built around vehicle-specific fitment data and dimensional accuracy for direct replacement use. Confirm the part number BC96788 against the vehicle application before installation.
| Year | Make | Model | Body Type | Bed Length | Wheel Base | Position | Notes |
|---|---|---|---|---|---|---|---|
| 2006 | Chevrolet | Silverado 1500 | — | — | 133.0" | Rear Left | Element3 |
| 2006 | Chevrolet | Silverado 1500 | — | — | 157.5" | Rear Left | Element3 |
| 2006 | Chevrolet | Silverado 1500 | — | — | 143.5" | Rear Left | Element3 |
| 2006 | GMC | Sierra 1500 | — | — | 133.0" | Rear Left | Element3 |
| 2006 | GMC | Sierra 1500 | — | — | 157.5" | Rear Left | Element3 |
| 2006 | GMC | Sierra 1500 | — | — | 143.5" | Rear Left | Element3 |
| 2005 | Chevrolet | Silverado 1500 | Standard Cab Pickup | 8' 0" Foot Bed | — | Rear Left | Vacuum Brake System; with 6400lb GVW; Element3 |
| 2005 | Chevrolet | Silverado 1500 | Extended Cab Pickup | 8' 0" Foot Bed | — | Rear Left | Vacuum Brake System; with 6400lb GVW; Element3 |
| 2005 | Chevrolet | Silverado 1500 | Extended Cab Pickup | 6' 6" Foot Bed | — | Rear Left | Vacuum Brake System; with 6400lb GVW; Element3 |
| 2005 | Chevrolet | Silverado 1500 | Extended Cab Pickup | 6' 6" Foot Bed | — | Rear Left | Vacuum Brake System; with 7000lb GVW; Element3 |
| 2005 | GMC | Sierra 1500 | — | — | 133.0" | Rear Left | Element3 |
| 2005 | GMC | Sierra 1500 | — | — | 157.5" | Rear Left | Element3 |
| 2005 | GMC | Sierra 1500 | — | — | 143.5" | Rear Left | Element3 |
