Raybestos BH35076 Brake Hydraulic Hose - Rear or Rear Center
| Brand | Raybestos BH35076 |
|---|---|
| Position | Rear |
| Fitting Type, End 1 | Female Thread - SAE |
| Fitting Type, End 2 | Male Thread |
| Gasket Or Seal Included | No |
| Hose Length, Overall | 13.600 |
| Product line | Element3 |
| Fits | Cadillac · 11 vehicles |
Brake hydraulic hose. Element3 line with SAE female-thread and male-thread fittings.
13.6-inch overall length for a precise hydraulic connection.
Cross-references Centric Parts 150.62004, Dorman - First Stop H35076 and Four Seasons 35076 for the same application. See all 14.
Raybestos Element3 Brake Hydraulic Hose BH35076
The Raybestos Element3 BH35076 is a brake hydraulic hose built for rear brake applications on select Cadillac vehicles. It uses a female thread SAE fitting on one end, a male thread fitting on the other, and measures 13.600 inches overall for the specified fitments.
Key Features
- Brake hydraulic hose for rear and rear center applications
- Overall hose length: 13.600 inches
- End 1 fitting type: female thread - SAE
- End 2 fitting type: male thread
- No gasket or seal included
- Raybestos Element3 line for brake service applications
Product Details
Raybestos BH35076 is a direct-fit brake hose for select 1961-1967 Cadillac models, including Cadillac Commercial Chassis and Cadillac Fleetwood applications. This Raybestos brake hose supports rear brake plumbing where the original hose routing, thread style, and length must match the vehicle’s hydraulic system. The Element3 line identifies the product family within Raybestos brake components, making BH35076 a relevant choice when replacing a worn or leaking rear brake hose on a Cadillac Commercial Chassis or Cadillac Fleetwood.
This part cross-references Dorman - First Stop H35076 and Gates 70145 for the same application.
What It Helps Address
- Brake fluid seepage at the hose assembly
- Cracked, swollen, or aged rubber brake hose material
- Restricted rear brake fluid flow
- Soft or inconsistent brake pedal response caused by hose deterioration
- Fitment issues when replacing an original rear brake hose on Cadillac Commercial Chassis or Fleetwood models
Installation Notes and Tips
Verify thread style, hose length, and routing before installation. BH35076 uses a female thread - SAE fitting on one end and a male thread fitting on the other, so matching the original connection points is important for proper brake line attachment. Confirm the rear or rear center position listed for your vehicle before ordering. For best results, inspect adjoining brake lines, fittings, and mounting points for corrosion or wear during replacement.
Quality Assurance
Raybestos Element3 brake components are cataloged for brake service applications with application-specific fitment data. Compatible With 1961-1964 Cadillac Commercial Chassis, rear center; 1965-1967 Cadillac Commercial Chassis, rear; and 1965-1967 Cadillac Fleetwood, rear.
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 1967 | Cadillac | Commercial Chassis | — | Rear | Element3 |
| 1967 | Cadillac | Fleetwood | Base | Rear | Element3 |
| 1966 | Cadillac | Commercial Chassis | — | Rear | Element3 |
| 1966 | Cadillac | Fleetwood | 60 Special | Rear | Element3 |
| 1966 | Cadillac | Fleetwood | Base | Rear | Element3 |
| 1965 | Cadillac | Commercial Chassis | — | Rear | Element3 |
| 1965 | Cadillac | Fleetwood | 60 Special | Rear | Element3 |
| 1964 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1963 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1962 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1961 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
