Raybestos BH36588 Brake Hydraulic Hose - Rear Center
| Brand | Raybestos BH36588 |
|---|---|
| Position | Rear Center |
| Fitting Type, End 1 | Block - SAE |
| Fitting Type, End 2 | Female Thread - SAE |
| Gasket Or Seal Included | No |
| Hose Length, Overall | 13.200 |
| Product line | Element3 |
| Fits | Cadillac and Chevrolet · 14 vehicles |
OE direct replacement. Brake hydraulic hose with SAE block and female-thread fittings.
Element3 line from Raybestos for dependable brake system service.
Cross-references Dayco 88484, 22.3409 and 36588 for the same application. See all 15.
Raybestos Element3 BH36588 Brake Hydraulic Hose
Raybestos Element3 BH36588 is a brake hydraulic hose built for rear center applications on select Cadillac and Chevrolet vehicles. It is specified with a block - SAE fitting on one end, a female thread - SAE fitting on the other, and an overall length of 13.200 inches for the listed applications.
Key Features
- Brake hydraulic hose for rear center placement
- Block - SAE fitting, end 1
- Female thread - SAE fitting, end 2
- Overall hose length: 13.200 inches
- No gasket or seal included
- Raybestos Element3 line for select OE-style brake service applications
Application Details
Compatible With 1971-1974 Cadillac Commercial Chassis, rear center; 1971-1974 Cadillac Fleetwood, rear center; 1969-1970 Chevrolet Bel Air, rear center; 1969-1970 Chevrolet Caprice, rear center; and 1969-1970 Chevrolet Impala, rear center. This Raybestos BH36588 brake hose is a direct-fit hydraulic line for the listed rear center brake routing on these Cadillac and Chevrolet models. This part cross-references Dayco 88484 for the same application.
What This Brake Hose Helps Address
- Cracked or deteriorated brake hose material
- Brake fluid seepage at the hose connection points
- Restricted hydraulic flow in the rear brake circuit
- Soft or inconsistent brake pedal response caused by hose wear
- Service replacement for aging rear center brake hose routing
Installation Notes and Tips
Verify the end fittings, hose length, and rear center routing before installation. Match the vehicle year, make, and model exactly to the listed applications for Raybestos BH36588, and inspect adjoining brake lines, brackets, and connection points for wear or corrosion during service. Proper brake bleeding is required after hose replacement.
Quality Assurance
Raybestos Element3 brake components are positioned for OE-style brake service on listed applications, with fitment defined for the specified Cadillac and Chevrolet vehicles. Confirm all connection details against the original hose before installation.
| Year | Make | Model | Submodel | Position | Notes |
|---|---|---|---|---|---|
| 1974 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1974 | Cadillac | Fleetwood | 75 | Rear Center | Element3 |
| 1973 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1973 | Cadillac | Fleetwood | 75 | Rear Center | Element3 |
| 1972 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1972 | Cadillac | Fleetwood | 75 | Rear Center | Element3 |
| 1971 | Cadillac | Commercial Chassis | — | Rear Center | Element3 |
| 1971 | Cadillac | Fleetwood | 75 | Rear Center | Element3 |
| 1970 | Chevrolet | Bel Air | — | Rear Center | Element3 |
| 1970 | Chevrolet | Caprice | — | Rear Center | Element3 |
| 1970 | Chevrolet | Impala | — | Rear Center | Element3 |
| 1969 | Chevrolet | Bel Air | — | Rear Center | Element3 |
| 1969 | Chevrolet | Caprice | — | Rear Center | Element3 |
| 1969 | Chevrolet | Impala | — | Rear Center | Element3 |
