Raybestos FRC11683N Disc Brake Caliper - Front Right

Reliable Disc Brake Caliper for Dodge and Mitsubishi Vehicles

The Raybestos Element3 Friction-Ready Caliper, part number FRC11683N, is designed to provide dependable braking performance for select Dodge and Mitsubishi models. This new, cast iron floating caliper includes a bracket and is engineered to meet the specific needs of vehicles like the Dodge Dakota, Dodge Ram 1500, and Mitsubishi Raider.

• Caliper casting material: durable cast iron
• Caliper type: floating design for consistent brake pad contact
• Includes two caliper pistons with a diameter of 2.122 inches
• Bleeder screw thread size: M10x1 for easy maintenance
• Caliper bracket mounting hole size: 14.000 mm with 2.000 mm thread pitch
• Semi-loaded caliper configuration for balanced performance
• Plain surface finish for straightforward installation
• New manufacturing type ensuring fresh components

About the Element3 Friction-Ready Caliper Line

The Element3; Friction-Ready Caliper, New; Includes Bracket line by Raybestos focuses on providing ready-to-install brake calipers that come complete with mounting brackets. This product line is designed to simplify brake system repairs by delivering components that meet OEM specifications and reduce installation time. The FRC11683N caliper fits within this line, offering a semi-loaded, floating caliper solution that is compatible with specific Dodge and Mitsubishi trucks.

Product Details and Specifications

This Raybestos disc brake caliper features a cast iron construction that ensures strength and durability under demanding braking conditions. The floating caliper design allows for even pad wear and reliable braking force. Equipped with two pistons measuring 2.122 inches in diameter, this caliper provides balanced pressure distribution. The included bracket has mounting holes sized at 14.000 mm with a 2.000 mm thread pitch, facilitating a secure fit. The bleeder screw thread size of M10x1 supports standard brake fluid bleeding procedures. The semi-loaded configuration means the caliper comes partially assembled, streamlining the installation process.

Compatible Vehicles and Common Applications

• Replacement for worn or damaged calipers on Dodge Dakota models
• Brake system upgrade or repair for Dodge Ram 1500 trucks
• Suitable for Mitsubishi Raider brake caliper replacement
• Addresses issues such as uneven brake pad wear and reduced braking efficiency
• Resolves brake fluid leakage and caliper piston sticking problems

Installation Notes and Tips

When installing the Raybestos FRC11683N caliper, ensure the mounting bracket is securely fastened using the specified 14.000 mm mounting holes and 2.000 mm thread pitch. Bleed the brake system thoroughly using the M10x1 bleeder screw to remove air and maintain optimal brake performance. Verify piston movement before installation to confirm smooth operation. This semi-loaded caliper design reduces assembly time but may require brake pad installation depending on your specific setup.

Quality Assurance and Warranty

Raybestos manufactures the FRC11683N caliper as a new component, adhering to strict quality standards for durability and performance. The cast iron construction and precise machining contribute to long service life. While specific warranty details are not provided here, Raybestos products typically come with manufacturer-backed warranties to protect against defects in materials and workmanship.
