Sealed Power 224-15105 Engine Oil Pump Screen
| Brand | Sealed Power 224-15105 |
|---|---|
| Tube Inside Diameter | 1.055 |
| Tube Inside Diameter | 26.80 |
| Grade Type | Premium |
| Gasket Or Seal Included | No |
| Tube Length | 139.95 |
| Tube Length | 5.510 |
| Screen Face Diameter | 2.500 |
| Screen Face Diameter | 63.50 |
| Part Description | Engine oil pump screen |
| Fits | Chevrolet and GMC · 15 vehicles |
Premium grade. Built for dependable oil pump screening performance.
Engine oil pump screen. Helps keep debris out of the oil pump.
Cross-references 419S and 12686433 for the same application. See all 2.
Sealed Power Engine Oil Pump Screen
The Sealed Power 224-15105 engine oil pump screen is a premium-grade replacement part for maintaining clean oil pickup flow in the engine block system. Built with a 1.055 in. (26.80 mm) tube inside diameter, 5.510 in. (139.95 mm) tube length, and 2.500 in. (63.50 mm) screen face diameter, it is made for direct-fit service on select Chevrolet and GMC trucks and vans.
- Brand: Sealed Power
- Part number: 224-15105
- Premium grade construction
- Engine oil pump screen for cylinder block component service
- Tube inside diameter: 1.055 in. / 26.80 mm
- Tube length: 5.510 in. / 139.95 mm
- Screen face diameter: 2.500 in. / 63.50 mm
- Gasket or seal included: No
Detailed Product Overview
This Sealed Power oil pump screen is a direct replacement component for the engine oil pickup system, helping maintain proper oil flow from the sump to the pump. It cross-references 419S and 12686433 for the same application. Use the 224-15105 when servicing compatible Chevrolet Express 2500, Chevrolet Express 3500, GMC Savana 2500, GMC Savana 3500, Chevrolet Silverado 1500, and GMC Sierra 1500 applications.
Vehicle Fitment
- Fits 2018-2019 Chevrolet Express 2500, N/A
- Fits 2018-2019 Chevrolet Express 3500, N/A
- Fits 2018-2019 GMC Savana 2500, N/A
- Fits 2018-2019 GMC Savana 3500, N/A
- Fits 2016-2018 Chevrolet Silverado 1500, N/A
- Fits 2015-2018 GMC Sierra 1500, N/A
What This Part Helps Address
- Restricted oil pickup flow caused by a worn or damaged screen
- Contamination entering the oil pump pickup path
- Oil pressure concerns related to pickup restriction
- Service replacement needs during engine block or oiling system repair
- Fitment-specific replacement for Chevrolet and GMC oiling system service
Installation Notes and Tips
Verify tube dimensions and screen face diameter against the original part before installation. Because no gasket or seal is included, reuse or replace sealing components as required by the application. Confirm vehicle coverage for 2015-2019 Chevrolet and GMC models before ordering the 224-15105.
Quality Assurance
Sealed Power supplies engine components with OE-style fitment focus and premium-grade construction standards. This part is identified for direct replacement use in the listed Chevrolet and GMC applications.
| Year | Make | Model | Liters | Cylinders | Notes |
|---|---|---|---|---|---|
| 2019 | Chevrolet | Express 2500 | 4.3L | V6 | — |
| 2019 | Chevrolet | Express 3500 | 4.3L | V6 | — |
| 2019 | GMC | Savana 2500 | 4.3L | V6 | — |
| 2019 | GMC | Savana 3500 | 4.3L | V6 | — |
| 2018 | Chevrolet | Express 2500 | 4.3L | V6 | — |
| 2018 | Chevrolet | Express 3500 | 4.3L | V6 | — |
| 2018 | Chevrolet | Silverado 1500 | 4.3L | V6 | — |
| 2018 | GMC | Savana 2500 | 4.3L | V6 | — |
| 2018 | GMC | Savana 3500 | 4.3L | V6 | — |
| 2018 | GMC | Sierra 1500 | 4.3L | V6 | — |
| 2017 | Chevrolet | Silverado 1500 | 4.3L | V6 | — |
| 2017 | GMC | Sierra 1500 | 4.3L | V6 | — |
| 2016 | Chevrolet | Silverado 1500 | 4.3L | V6 | — |
| 2016 | GMC | Sierra 1500 | 4.3L | V6 | — |
| 2015 | GMC | Sierra 1500 | 4.3L | V6 | — |
