Sealed Power 224-43626 Engine Oil Pump

Engine Oil Pump for Ford Super Duty Applications

Sealed Power 224-43626 is a premium engine oil pump built for Ford truck and van applications that require standard oil volume and standard pressure. It features a cast iron housing, rotary pump design, crankshaft drive type, and an included gasket or seal for a direct replacement service.

Compatible With 1994-2003 Ford F-250, F-350, E-350 Econoline, E-350 Econoline Club Wagon, E-350 Club Wagon, E-350 Super Duty, F-250 HD, and Excursion applications listed below. Sealed Power 224-43626 is also cross-referenced with 1830813C92 and F4TZ6616A for the same application.

Key Features

• Premium-grade engine oil pump
• Cast iron housing for durability
• Rotary oil pump design
• Crankshaft-driven operation
• Standard volume and standard pressure output
• Gasket or seal included
• 4 mounting holes with 0.375 in. mounting hole diameter
• Dimensions: 5.500 in. height, 2.120 in. width

Detailed Description

This Sealed Power engine oil pump is engineered for Ford diesel and heavy-duty gasoline applications where consistent oil delivery is critical. The improved design and standard-volume, standard-pressure configuration make it a direct-fit replacement for many Ford E-Series, F-Series Super Duty, and Excursion models. Part number 224-43626 is built with ISO and QS certified manufacturing practices and uses modern materials to meet the demands of current engine service requirements.

Use this oil pump when servicing a Ford E-350 Super Duty, F-250 Super Duty, or F-350 Super Duty engine that calls for the listed fitment and specifications. The cast iron construction and rotary pump layout support dependable oil circulation in demanding truck and van duty cycles.

What This Part Helps Address

• Low oil pressure caused by a worn or failing pump
• Inconsistent oil circulation in high-mileage engines
• Noise or wear related to inadequate lubrication
• Oil delivery concerns during engine rebuild or overhaul
• Replacement needs for Ford truck and van oil pump service

Installation Notes and Tips

Verify engine application, pump drive type, and pressure/volume requirements before installation. This pump uses a crankshaft drive and is not for injector driver applications. Confirm mounting hole alignment, gasket or seal placement, and clean all mating surfaces before assembly. Always prime the oiling system and follow the vehicle service manual for torque and startup procedures.

Quality Assurance

Sealed Power parts are manufactured with innovative designs, advanced materials, and ISO and QS certified processes to support consistent product quality. Part number 224-43626 is built to meet the demands of modern engine service and replacement work.
