Sealed Power 2305CP Engine Connecting Rod Bearing

Overview of Sealed Power Engine Connecting Rod Bearing 2305CP

The Sealed Power 2305CP engine connecting rod bearing is engineered for reliable performance in Ford, Lincoln, and Mercury vehicles, including models like the Colony Park, Continental, and Thunderbird. Designed to meet precise specifications, this bearing supports optimal engine function and durability.

• Housing Bore Diameter: 2.7522 to 2.7530 inches (69.9060 to 69.9260 mm)
• Oil Clearance Range: 0.0006 to 0.0032 inches (0.0150 to 0.0810 mm)
• Overall Length: Maximum 0.8660 inches (22.0000 mm)
• Standard Shaft Diameter: 2.5992 to 2.6000 inches (66.0200 to 66.0400 mm)
• Wall Thickness: Maximum 0.0758 inches (1.9250 mm)

Technical Specifications and Performance Details

The 2305CP connecting rod bearing from Sealed Power is manufactured to exacting tolerances to ensure proper fit and function within the engine assembly. The housing bore dimensions range narrowly between 2.7522 and 2.7530 inches, providing a precise fit for the connecting rod journal. Oil clearance is carefully controlled between 0.0006 and 0.0032 inches, which is critical for maintaining adequate lubrication and minimizing wear during engine operation. The bearing’s overall length of up to 0.8660 inches and wall thickness of 0.0758 inches contribute to its structural integrity and durability under high-stress conditions.

Compatible Vehicles and Applications

This engine connecting rod bearing is compatible with select Ford, Lincoln, and Mercury models, specifically the Colony Park, Continental, and Thunderbird. It is designed to replace worn or damaged bearings in these vehicles, ensuring continued engine reliability and performance.

• Reduces engine knocking caused by worn bearings
• Prevents excessive oil consumption due to improper clearance
• Minimizes bearing wear and potential engine damage
• Restores proper oil clearance for efficient lubrication
• Supports smooth engine operation and longevity

Installation Notes and Tips

When installing the Sealed Power 2305CP connecting rod bearing, ensure the housing bore and shaft dimensions are within specified tolerances. Proper cleaning of the bearing surfaces and lubrication with engine oil before installation is recommended. Verify oil clearance using plastigage or a similar measuring tool to confirm it falls within the 0.0006 to 0.0032 inch range. Follow manufacturer torque specifications for connecting rod bolts to avoid distortion or damage.

Quality Assurance and Warranty Information

Sealed Power bearings are manufactured under strict quality control standards to meet OEM specifications. The 2305CP bearing undergoes rigorous testing to ensure dimensional accuracy and material integrity. While specific warranty details may vary, Sealed Power products typically include coverage against manufacturing defects, providing confidence in product reliability for Ford, Lincoln, and Mercury vehicle owners.
