Stabilus 6G-1135DL Engine Torque Strut
OE Quality 60-Day Returns
Stabilus

Stabilus 6G-1135DL Engine Torque Strut

Brand Stabilus 6G-1135DL
Y
Y
Body 0.945
Compressed Length 3.957
Compressed Length 100.5
Extended Length 5.138
Extended Length 130.5
Force (N) 0
Force Lbs 0
Hardware Kit NO
Rod Connection M6 THREAD
Rod Dia (IN) 0.315
Rod Diameter 8
Rod End Attachment Dia (IN) 0.236
Rod End Attachment Dia (MM) 6
Shaft 0.315
Shaft Connection M6 THREAD
Tube Connection M6 THREAD
Tube Dia (IN) 0.945
Tube Diameter 24
Tube End Attach Dia (IN) 0.236
Tube End Attach Dia (mm) 6
Fits Mercedes-Benz · 54 vehicles

Threaded connections. M6 thread ends simplify secure attachment.

Compact gas strut. Slim 0.945 in body fits tight packaging.

Cross-references Stabilus 6G-1135DL, 1135DL and A1232400548 for the same application. See all 6.

$43.87Free shipping
In stock · usually ships same day before 1pm CST
Step 1 — Confirm fitment
Free return shipping if it doesn't fit when you check fitment here first.
Select your vehicle to confirm fitment
Verify this part fits before purchasing — free returns if it doesn't
Step 2 — Quantity
Engine Torque Struts are typically replaced in pairs, axle by axle.
Order total $43.87
Free shipping to the continental U.S.
Free returns within 60 days if it doesn't fit when fitment is verified.
Not what you need? See all Engine Torque Strut options

Mercedes-Benz Engine Torque Strut 6G-1135DL

The Stabilus 6G-1135DL engine torque strut is a direct-fit engine damper for select Mercedes-Benz models. It is built with M6 thread connections and OE-style dimensions to match the original mounting points on supported W126 and R107 applications.

Key Features

  • Brand: Stabilus
  • Part number: 6G-1135DL
  • Engine torque strut / engine damper for Mercedes-Benz applications
  • Compressed length: 100.5 mm (3.957 in)
  • Extended length: 130.5 mm (5.138 in)
  • Rod diameter: 8 mm (0.315 in)
  • Tube diameter: 24 mm (0.945 in)
  • Rod connection: M6 thread
  • Tube connection: M6 thread
  • Rod end attachment diameter: 6 mm (0.236 in)
  • Tube end attachment diameter: 6 mm (0.236 in)

Detailed Description

Stabilus 6G-1135DL is an engine torque strut used to control engine movement and reduce drivetrain motion in select Mercedes-Benz vehicles. This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application. It is listed for 1981-1985 Mercedes-Benz 300SD, 1977-1981 Mercedes-Benz 300D, 1984-1985 Mercedes-Benz 380SE, 1981-1983 Mercedes-Benz 380SEL, 1982-1983 Mercedes-Benz 380SEC, 1984-1985 Mercedes-Benz 500SEL, 1984-1985 Mercedes-Benz 500SEC, 1986-1991 Mercedes-Benz 420SEL, 1986-1991 Mercedes-Benz 560SEL, 1986-1991 Mercedes-Benz 560SEC, 1986-1987 Mercedes-Benz 300SDL, 1986-1989 Mercedes-Benz 560SL, 1981-1985 Mercedes-Benz 380SL, 1981-1983 Mercedes-Benz 380SLC, and 1978-1980 Mercedes-Benz 300SD. Use the part number 6G-1135DL to verify the correct engine damper for your specific chassis and model year.

What It Helps Address

  • Excessive engine rocking during acceleration or deceleration
  • Clunking or driveline movement caused by worn torque control components
  • Harsh engine motion under load
  • Reduced stability of the engine assembly in supported Mercedes-Benz models
  • Fitment issues when replacing an original Mercedes-Benz engine damper with the correct OE-style part

Installation Notes and Tips

Confirm the chassis code, model year, and mounting style before ordering. This part uses M6 thread connections and specific compressed and extended lengths, so matching the original damper dimensions is important for proper alignment. For Mercedes-Benz 560SL, 380SL, and 380SLC applications, verify the engine damper configuration against the vehicle’s original setup before installation.

Quality Assurance

Stabilus manufactures this engine torque strut to OE-style dimensional specifications for the listed Mercedes-Benz applications. The part number 6G-1135DL is also referenced by 1135DL, A1232400548, A1232401048, SG403011, and TSG403011 for application matching.

Related reading

This part fits 54 vehicles
Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
YearMakeModelLitersCylindersFuel TypePositionNotes
1991Mercedes-Benz420SEL———N/A(W126)
1991Mercedes-Benz560SEC———N/A(W126)
1991Mercedes-Benz560SEL———N/A(W126)
1990Mercedes-Benz420SEL———N/A(W126)
1990Mercedes-Benz560SEC———N/A(W126)
1990Mercedes-Benz560SEL———N/A(W126)
1989Mercedes-Benz420SEL———N/A(W126)
1989Mercedes-Benz560SEC———N/A(W126)
1989Mercedes-Benz560SEL———N/A(W126)
1989Mercedes-Benz560SL———N/A(R107) engine damper
1988Mercedes-Benz420SEL———N/A(W126)
1988Mercedes-Benz560SEC———N/A(W126)
1988Mercedes-Benz560SEL———N/A(W126)
1988Mercedes-Benz560SL———N/A(R107) engine damper
1987Mercedes-Benz300SDL3.0LL6DIESELN/A(W126)
1987Mercedes-Benz420SEL———N/A(W126)
1987Mercedes-Benz560SEC———N/A(W126)
1987Mercedes-Benz560SEL———N/A(W126)
1987Mercedes-Benz560SL———N/A(R107) engine damper
1986Mercedes-Benz300SDL3.0LL6DIESELN/A(W126)
1986Mercedes-Benz420SEL———N/A(W126)
1986Mercedes-Benz560SEC———N/A(W126)
1986Mercedes-Benz560SEL———N/A(W126)
1986Mercedes-Benz560SL———N/A(R107) engine damper
1985Mercedes-Benz300SD3.0LL5DIESELN/A(W126)
1985Mercedes-Benz380SE———N/A(W126)
1985Mercedes-Benz380SL———N/A(R107) engine damper
1985Mercedes-Benz500SEC———N/A(W126)
1985Mercedes-Benz500SEL———N/A(W126)
1984Mercedes-Benz300SD3.0LL5DIESELN/A(W126)
1984Mercedes-Benz380SE———N/A(W126)
1984Mercedes-Benz380SL———N/A(R107) engine damper
1984Mercedes-Benz500SEC———N/A(W126)
1984Mercedes-Benz500SEL———N/A(W126)
1983Mercedes-Benz300SD3.0LL5DIESELN/A(W126)
1983Mercedes-Benz380SEC———N/A(W126)
1983Mercedes-Benz380SEL———N/A(W126)
1983Mercedes-Benz380SL———N/A(R107) engine damper
1982Mercedes-Benz300SD3.0LL5DIESELN/A(W126)
1982Mercedes-Benz380SEC———N/A(W126)
1982Mercedes-Benz380SEL———N/A(W126)
1982Mercedes-Benz380SL———N/A(R107) engine damper
1981Mercedes-Benz300D———N/A(W123)
1981Mercedes-Benz300SD3.0LL5DIESELN/A(W126)
1981Mercedes-Benz380SEL———N/A(W126)
1981Mercedes-Benz380SL———N/A(R107) engine damper
1981Mercedes-Benz380SLC———N/A(R107) engine damper
1980Mercedes-Benz300D———N/A(W123)
1980Mercedes-Benz300SD3.0LL5DIESELN/A(W116)
1979Mercedes-Benz300D———N/A(W123)
1979Mercedes-Benz300SD3.0LL5DIESELN/A(W116)
1978Mercedes-Benz300D———N/A(W123)
1978Mercedes-Benz300SD3.0LL5DIESELN/A(W116)
1977Mercedes-Benz300D———N/A(W123)
Directly replaces or cross-references 6 part numbers
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
Stabilus — 6G-1135DL1135DLA1232400548A1232401048SG403011TSG403011
