Stabilus 6G-1158DL Engine Torque Strut

Engine Torque Strut Overview

This Stabilus engine torque strut, part number 6G-1158DL, is built for Mercedes-Benz W201 applications and uses threaded M6 connections for a direct mechanical attachment. It is listed for Mercedes-Benz 190E and 190D fitments across the 1984-1993 model years.

• Fits 1984-1990 Mercedes-Benz 190E, N/A.
• Fits 1991 Mercedes-Benz 190E, N/A, W201.
• Fits 1992-1993 Mercedes-Benz 190E, N/A.
• Fits 1984-1989 Mercedes-Benz 190D, N/A, W201.

Key Features

• Stabilus replacement torque strut for engine movement control.
• M6 threaded rod, shaft, and tube connections for secure attachment.
• Compressed length of 139 mm and extended length of 169 mm.
• 8 mm rod diameter with a 24 mm tube diameter.
• Part number 6G-1158DL for catalog matching and service lookup.

Detailed Description

The 6G-1158DL is an engine torque strut designed to help control drivetrain movement in Mercedes-Benz 190E and 190D applications. Its threaded connection points and compact dimensions make it a fitment-specific replacement for W201 chassis vehicles, including 1984-1990 Mercedes-Benz 190E, 1991 Mercedes-Benz 190E, 1992-1993 Mercedes-Benz 190E, and 1984-1989 Mercedes-Benz 190D. The Stabilus 6G-1158DL is identified by a 139 mm compressed length, 169 mm extended length, and 8 mm rod diameter, which are important reference points when matching the correct engine torque strut for service.

This part cross-references Monroe Shocks & Struts (e.g., 1158DL, SG403015) for the same application.

What It Is Used For

• Excessive engine movement under load.
• Drivetrain vibration felt during acceleration or shifting.
• Worn or damaged torque strut mounting points.
• Incorrect replacement part selection during service.

Installation Notes and Tips

Verify the vehicle year, model, and W201 chassis notes before ordering. Match the threaded connection style and overall length to the original part to confirm proper fitment. Because hardware kit information is not included, plan to inspect existing fasteners and mounting points during installation.

Quality Assurance

Stabilus is a recognized OE supplier in gas spring and motion-control applications, and this torque strut follows the dimensional and connection details needed for accurate replacement selection. Part number 6G-1158DL should be matched against the original unit and vehicle fitment data before installation.
