Standard ALS468T Tire Pressure Monitoring System (TPMS) Sensor - Rear Right

OE-Style TPMS Sensor for Rear Right Wheels

The Standard ALS468T is a tire pressure monitoring system sensor for the rear right wheel position on select Volkswagen and Audi applications. It is built as a bolt-mount, wheel-mounted TPMS sensor with a female connector, oval connector shape, and blade terminals for OE-style replacement service.

Key Features

• Part number: ALS468T
• Tire Pressure Monitoring System (TPMS) sensor for wheel mounting
• Bolt-mount design with 1 bolt hole
• Rear right position applications
• Female connector, oval connector shape, and 2 terminals
• Blade terminal type with male terminal gender
• No harness, dust shield, or mounting hardware included

Detailed Description

Standard ALS468T is a direct-fit TPMS sensor for vehicles that use an OE design sensor at the rear right wheel. It serves Volkswagen Passat, Beetle, Jetta, Tiguan, Golf, GTI, Eos, CC, Golf SportWagen, Tiguan Limited, Golf City, Jetta City, R32, Passat CC, and Audi A3, A3 Quattro, A3 Quattro, TT, TTS Quattro, TT RS Quattro, and Q3 applications listed in the fitment data. This part cross-references 1K0927808 and SU11905 for the same application.

What It Helps Address

• TPMS warning light triggered by a failed rear right sensor
• Loss of tire pressure data from the wheel-mounted sensor
• Intermittent sensor communication on Volkswagen and Audi TPMS systems
• Replacement needs after sensor battery or internal electronics failure
• OE-design sensor service on rear right wheel positions

Installation Notes and Tips

Install ALS468T at the rear right wheel position only where the catalog lists OE design sensor coverage. Verify the vehicle year, make, model, and notes such as w/o Automated Parking Assist before installation. Because this is a bolt-mount sensor with no harness, dust shield, or mounting hardware included, reuse or source the correct vehicle-specific components as required by the application. After installation, perform the appropriate TPMS relearn or sensor registration procedure for the vehicle.

Quality Assurance

Standard Ignition supplies this TPMS sensor as an OE-style replacement part for listed Volkswagen and Audi applications. The ALS468T is built to match the connector, terminal, and mounting style used in the cataloged fitments for consistent service replacement.
