Standard Ignition ALS1380 Tire Pressure Monitoring System Sensor - Rear
| Brand | Standard Ignition ALS1380 |
|---|---|
| Position | Rear |
| Connector Gender | Female |
| Connector Shape | Rectangular |
| Mounting Location | Differential |
| Number of Bolt Holes | 0 |
| Terminal Gender | Male |
| Terminal Type | Blade |
| Fits | Toyota and Scion · 15 vehicles |
TPMS sensor. Monitors tire pressure for timely alerts and maintenance.
Rectangular connector. Female connector with male blade terminals for secure electrical connection.
Differential mounting. Built for a differential-mounted sensor application.
Cross-references Dayco 70846, Delphi SS20959 and Dorman - OE Solutions 970-408 for the same application. See all 14.
Standard Ignition ALS1380 TPMS Sensor Overview
Standard Ignition ALS1380 is a tire pressure monitoring system sensor for rear applications on select Toyota and Scion vehicles. It is listed for the Toyota Prius, Scion tC, and Toyota Celica, with fitment coverage that includes 2000-2009 model years.
This TPMS sensor uses a rectangular connector with a female connector gender, male blade terminals, and a differential mounting location. Standard Ignition ALS1380 is a direct-fit replacement for vehicles that use this sensor configuration and rear placement.
Key Features
- Part number: ALS1380
- Tire Pressure Monitoring System (TPMS) sensor for rear mounting locations
- Rectangular connector shape with 1 connector
- Female connector gender and male terminal gender
- 2 terminals with blade terminal type
- Differential mounting location
- Compatible with select Toyota Prius, Scion tC, and Toyota Celica applications
Fitment Details
- Fits 2004-2009 Toyota Prius, rear.
- Fits 2005-2006 Scion tC, rear, NSK.
- Fits 2005 Scion tC, rear, NSK; No programming required. Install sensor and follow the OEM factory relearn procedure.
- Fits 2000-2005 Toyota Celica, rear, NSK.
Cross-reference part numbers for the same application include Dorman - OE Solutions 970-408 and Delphi SS20959.
What This Sensor Helps Address
- TPMS warning light caused by a failed rear sensor
- Loss of tire pressure signal from the wheel-end monitoring system
- Incorrect or missing pressure data on the instrument cluster
- Sensor replacement needs on Toyota Prius, Scion tC, and Toyota Celica rear positions
- Service repairs after battery or sensor failure in the TPMS system
Installation Notes and Tips
Verify rear-position fitment, connector style, and terminal configuration before installation. For the 2005 Scion tC application, no programming is required; install the sensor and follow the OEM factory relearn procedure. Confirm the vehicle’s TPMS service procedure and relearn steps after installation.
Quality Assurance
Standard Ignition supplies replacement electrical and sensor components for automotive service applications. ALS1380 is cataloged with OE-style interchange references for the listed Toyota and Scion rear fitments.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2009 | Toyota | Prius | Rear | — |
| 2008 | Toyota | Prius | Rear | — |
| 2007 | Toyota | Prius | Rear | — |
| 2006 | Scion | tC | Rear | NSK |
| 2006 | Toyota | Prius | Rear | — |
| 2005 | Scion | tC | Rear | NSK; No programming required. Install sensor and follow the OEM factory relearn procedure. |
| 2005 | Scion | tC | Rear | NSK |
| 2005 | Toyota | Celica | Rear | NSK |
| 2005 | Toyota | Prius | Rear | — |
| 2004 | Toyota | Celica | Rear | NSK |
| 2004 | Toyota | Prius | Rear | — |
| 2003 | Toyota | Celica | Rear | NSK |
| 2002 | Toyota | Celica | Rear | NSK |
| 2001 | Toyota | Celica | Rear | NSK |
| 2000 | Toyota | Celica | Rear | NSK |
