Standard Ignition ALS3012 Tire Pressure Monitoring System Sensor - Front Left
| Brand | Standard Ignition ALS3012 |
|---|---|
| Position | Front Left |
| Connector Gender | Female |
| Connector Shape | Rectangular |
| Harness Length - inches | 28.5" |
| Harness Length - mm | 720 mm |
| Mounting Location | Wheel |
| Mounting Type | Bolt Mount |
| Number of Bolt Holes | 1 |
| Terminal Gender | Male |
| Terminal Type | Pin |
| Fits | Honda · 13 vehicles |
Bolt-mount design. Installs securely with a single bolt hole.
Wheel-mounted sensor. Monitors tire pressure from the wheel assembly.
Female connector. Uses a rectangular connector with pin terminals.
Cross-references Standard Ignition ALS3012, 57455TBAA02 and 533383 for the same application. See all 5.
Standard Ignition ALS3012 TPMS Sensor
The Standard Ignition ALS3012 is a bolt-mount tire pressure monitoring system sensor for wheel-mounted applications. It is built for direct replacement use on select Honda Civic and Honda Insight front left positions, with fitment that follows the OEM factory relearn procedure and requires no programming.
Key Features
- Part number ALS3012 TPMS sensor for wheel-mounted installation
- Bolt-mount design with one bolt hole
- Front left fitment for select Honda Civic and Honda Insight applications
- 28.5 in. harness length for the specified vehicle routing
- Female connector with one rectangular connector and 2 terminals
- Pin-type terminal design
- Direct replacement cross-reference for 57455TBAA02 and 533383
Detailed Description
Standard Ignition ALS3012 is a tire pressure monitoring system sensor engineered for wheel mounting on the front left position. This TPMS sensor matches the listed Honda applications and supports OEM-style relearn procedures without programming, making it a practical replacement when the original sensor is no longer reporting tire pressure data correctly. The ALS3012 part number is also referenced as ABS3012 in interchange listings for the same application.
Compatible With 2019-2022 Honda Insight, front left. Compatible With 2020-2021 Honda Civic, front left. Compatible With 2016-2017 Honda Civic, front left. Compatible With 2016-2020 Honda Civic, front left, install sensor and follow OEM factory relearn procedure, no programming required.
Common TPMS Issues This Sensor Addresses
- TPMS warning light stays illuminated after tire service
- Sensor signal loss from a failed wheel-mounted sensor
- Incorrect or missing tire pressure readings at the dash
- Need for a direct replacement on the front left wheel position
- Replacement after tire rotation, wheel service, or sensor aging
Installation Notes and Tips
Install the sensor at the wheel location specified in the fitment data and follow the OEM factory relearn procedure after installation. No programming is required for the listed 2016-2020 Honda Civic application note. Verify connector style, terminal layout, harness length, and bolt-mount configuration before installation to confirm the sensor matches the vehicle’s original setup.
Quality Assurance
Standard Ignition supplies OE-style replacement electrical and sensor components for service applications. ALS3012 is listed with direct interchange references and vehicle-specific fitment data to support accurate replacement selection for Honda Civic and Honda Insight TPMS service.
| Year | Make | Model | Body Type | # Doors | Position | Notes |
|---|---|---|---|---|---|---|
| 2022 | Honda | Insight | Sedan | — | Front Left | — |
| 2021 | Honda | Civic | Sedan | — | Front Left | — |
| 2021 | Honda | Insight | Sedan | — | Front Left | — |
| 2020 | Honda | Civic | Hatchback | — | Front Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2020 | Honda | Civic | — | 2 Door | Front Left | — |
| 2020 | Honda | Insight | Sedan | — | Front Left | — |
| 2019 | Honda | Civic | Hatchback | — | Front Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2019 | Honda | Insight | Sedan | — | Front Left | — |
| 2018 | Honda | Civic | Hatchback | — | Front Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2017 | Honda | Civic | Hatchback | — | Front Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2017 | Honda | Civic | Coupe | — | Front Left | — |
| 2016 | Honda | Civic | — | 2 Door | Front Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2016 | Honda | Civic | — | 2 Door | Front Left | — |
