Standard Ignition ALS488 Tire Pressure Monitoring System Sensor - Rear Left
| Brand | Standard Ignition ALS488 |
|---|---|
| Position | Rear Left |
| Connector Gender | Female |
| Connector Shape | Round |
| Harness Length - inches | 38 |
| Harness Length - mm | 960 |
| Mounting Location | Wheel |
| Number of Bolt Holes | 1 |
| Terminal Gender | Male |
| Terminal Type | Pin |
| Fits | Ford and Mercury · 16 vehicles |
Wheel-mounted sensor. Monitors tire pressure with a single-bolt design.
Round connector. Female connector with two-pin terminals for secure attachment.
38-inch harness. Provides generous reach for flexible installation.
Cross-references Cardone Reman 72-6205, Dorman - OE Solutions 695-042 and Gates 71018 for the same application. See all 12.
TPMS Sensor for Ford and Mercury Rear Left
Standard Ignition ALS488 is a tire pressure monitoring system sensor for rear left wheel applications on select Ford and Mercury vehicles. It is built with a wheel-mounted design, a round female connector, and a 38-inch harness for the specified OE-style fitment.
Key Features
- Wheel-mounted TPMS sensor for rear left applications
- Round female connector with 1 connector and 2 male pin terminals
- 38-inch (960 mm) harness length
- Single bolt-hole mounting design
- Built for select Ford Taurus, Taurus X, Five Hundred, Freestyle, and Mercury Sable and Montego applications
Detailed Description
Standard Ignition ALS488 is a TPMS sensor for rear left wheel positions on select 2005-2009 Ford and Mercury models. It is listed for 2008-2009 Ford Taurus, 2008-2009 Ford Taurus X, 2008-2009 Mercury Sable, 2005-2007 Ford Five Hundred, 2005-2007 Ford Freestyle, and 2005-2007 Mercury Montego. For 2007 Ford Freestyle, install the sensor and follow the OEM factory relearn procedure; no programming is required.
This part cross-references Dorman - OE Solutions 695-042 for the same application. ALS488 is a direct-fit service part for rear left TPMS service on Ford Taurus and Mercury Sable platforms where the OE sensor location and connector style match the listed specifications.
Common Issues This Part Can Help Resolve
- TPMS warning light caused by a failed rear left sensor
- Incorrect tire pressure readings from the wheel sensor
- Loss of sensor signal after battery or sensor failure
- Service replacement needs after wheel or tire work
- OE sensor replacement on listed Ford and Mercury models
Installation Notes and Tips
Verify rear left position, connector style, and harness length before installation. After mounting, follow the vehicle-specific OEM relearn procedure to register the sensor. Confirm fitment against the listed year, make, model, and position for Ford Taurus, Taurus X, Sable, Five Hundred, Freestyle, and Montego applications.
Quality Assurance
Standard Ignition manufactures with controlled production processes and quality oversight from component sourcing through finished product. The brand states broad sensor coverage and precision-focused engineering for durable service life.
| Year | Make | Model | Drive Type | Position | Notes |
|---|---|---|---|---|---|
| 2009 | Ford | Taurus | AWD | Rear Left | — |
| 2009 | Ford | Taurus X | AWD | Rear Left | — |
| 2009 | Mercury | Sable | AWD | Rear Left | — |
| 2008 | Ford | Taurus | AWD | Rear Left | — |
| 2008 | Ford | Taurus X | AWD | Rear Left | — |
| 2008 | Mercury | Sable | AWD | Rear Left | — |
| 2007 | Ford | Five Hundred | AWD | Rear Left | — |
| 2007 | Ford | Freestyle | AWD | Rear Left | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2007 | Ford | Freestyle | AWD | Rear Left | — |
| 2007 | Mercury | Montego | AWD | Rear Left | — |
| 2006 | Ford | Five Hundred | AWD | Rear Left | — |
| 2006 | Ford | Freestyle | AWD | Rear Left | — |
| 2006 | Mercury | Montego | AWD | Rear Left | — |
| 2005 | Ford | Five Hundred | AWD | Rear Left | — |
| 2005 | Ford | Freestyle | AWD | Rear Left | — |
| 2005 | Mercury | Montego | AWD | Rear Left | — |
| No rows match your filter. | |||||
