Standard Ignition ALS653 Tire Pressure Monitoring System Sensor - Rear Right
| Brand | Standard Ignition ALS653 |
|---|---|
| Position | Rear Right |
| Connector Gender | Male |
| Connector Shape | Rectangular |
| Harness Length - inches | 41 |
| Harness Length - mm | 1041.4 |
| Mounting Location | Wheel |
| Number of Bolt Holes | 4 |
| Terminal Gender | Female |
| Terminal Type | Blade |
| Fits | Pontiac and Toyota · 10 vehicles |
TPMS sensor. Monitors tire pressure for safer, more consistent driving.
Wheel-mounted design. Built for a secure fit at the wheel.
Rectangular connector. Uses a single male connector with blade terminals.
Cross-references Standard Ignition ALS653, 2ABS0242 and 5S6901 for the same application. See all 14.
Standard Ignition ALS653 TPMS Sensor
The Standard Ignition ALS653 is a tire pressure monitoring system sensor for the rear right wheel position on select Pontiac Vibe and Toyota Matrix models. It is built with a wheel-mounted design and a 41-inch harness for applications that require a direct sensor connection at the wheel.
Key Features
- TPMS sensor for tire pressure monitoring system service
- Wheel-mounted installation location
- Rear right position fitment on listed applications
- Male connector with rectangular connector shape
- 2 terminals with female blade terminal type
- 41-inch harness length for routing at the wheel
- 4-bolt-hole mounting pattern
- Standard Ignition ALS653 replacement part number
Fitment and Application Details
Compatible with 2003-2006 Pontiac Vibe, rear right, and 2003-2006 Toyota Matrix, rear right. It also fits 2005-2006 Toyota Matrix, rear right, with install sensor and follow OEM factory relearn procedure, no programming required. The ALS653 is a direct-fit TPMS sensor solution for drivers searching for a rear right TPMS sensor for Pontiac Vibe or Toyota Matrix service.
This part cross-references Monroe Shocks & Struts (e.g., 172286, 182286) for the same application.
What It Is Used For
- Replacing a failed rear right TPMS sensor
- Restoring tire pressure monitoring system warning function
- Addressing TPMS light concerns caused by sensor signal loss
- Servicing wheel-mounted sensor assemblies on listed vehicles
- Supporting proper tire pressure monitoring after sensor replacement
Installation Notes and Tips
Install the sensor at the wheel position listed for the vehicle application. For 2005-2006 Toyota Matrix fitment, follow the OEM factory relearn procedure after installation; no programming is required. Verify connector style, terminal configuration, and mounting location before installation to confirm the ALS653 matches the original sensor layout.
Quality Assurance
Standard Ignition supplies automotive electrical and sensor components for replacement service. The ALS653 is built to match the listed fitment and connector specifications for the confirmed Pontiac Vibe and Toyota Matrix rear right applications.
| Year | Make | Model | Drive Type | Position | Notes |
|---|---|---|---|---|---|
| 2006 | Pontiac | Vibe | AWD | Rear Right | — |
| 2006 | Toyota | Matrix | AWD | Rear Right | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2006 | Toyota | Matrix | AWD | Rear Right | — |
| 2005 | Pontiac | Vibe | AWD | Rear Right | — |
| 2005 | Toyota | Matrix | AWD | Rear Right | Install sensor and follow OEM factory relearn procedure, no programming required. |
| 2005 | Toyota | Matrix | AWD | Rear Right | — |
| 2004 | Pontiac | Vibe | AWD | Rear Right | — |
| 2004 | Toyota | Matrix | AWD | Rear Right | — |
| 2003 | Pontiac | Vibe | AWD | Rear Right | — |
| 2003 | Toyota | Matrix | AWD | Rear Right | — |
