OE Quality
60-Day Returns
Standard Ignition ALS765 Tire Pressure Monitoring System Sensor - Front Right
Standard Ignition ALS765 TPMS Sensor
The Standard Ignition ALS765 is a tire pressure monitoring system sensor for the wheel-mounted front right position on select Toyota RAV4 models. It is built for direct replacement service on 2001-2005 Toyota RAV4 applications, with 2004-2005 Toyota RAV4 fitment calling for sensor installation and the OEM factory relearn procedure, with no programming required.
- Part number: ALS765
- Category: Tire Pressure Monitoring System (TPMS) sensor
- Mounting location: Wheel
- Fitment position: Front right
- Connector configuration: 1 rectangular female connector
- Terminal configuration: 2 terminals, male blade type
- Harness length: 43.75 in. (1111.3 mm)
- Mounting design: 1 bolt hole
- Hardware included: No
Fitment and application details
Compatible with 2001-2005 Toyota RAV4 front right applications, this ALS765 TPMS sensor supports the factory tire pressure monitoring setup used on these vehicles. For 2004-2005 Toyota RAV4 front right service, install the sensor and follow the OEM relearn procedure; no programming is required. This part cross-references Beck/Arnley 084-4281 for the same application.
What this sensor helps address
- TPMS warning light caused by a failed wheel sensor
- Incorrect tire pressure readings from a damaged sensor
- Loss of signal from the front right wheel position
- Service replacement needs after sensor battery or internal failure
- Restoration of factory monitoring on Toyota RAV4 models
Installation notes and tips
Install the sensor at the wheel location specified for the front right position and verify connector and terminal orientation before assembly. On 2004-2005 Toyota RAV4 applications, complete the OEM factory relearn procedure after installation. Confirm vehicle year and position match the listed fitment before ordering the ALS765.
Quality assurance
Standard Ignition supplies replacement electrical and sensor components for service applications, and the ALS765 is listed with direct OE-style fitment references for select Toyota RAV4 models. Use the confirmed vehicle year and front right position to ensure proper application.
| Brand | Standard Ignition |
|---|---|
| Part Number | ALS765 |
| Connector Gender | Female |
| Connector Shape | Rectangular |
| Harness Length - inches | 43.75" |
| Harness Length - mm | 1111.3 |
| Mounting Location | Wheel |
| Number of Bolt Holes | 1 |
| Terminal Gender | Male |
| Terminal Type | Blade |
This part fits 9 vehicles. Search below:
| Year | Make | Model | Drive Type | Fuel Type | Position | Notes |
|---|---|---|---|---|---|---|
| 2005 | Toyota | RAV4 | Front Right | Install sensor and follow OEM factory relearn procedure, no programming required. | ||
| 2005 | Toyota | RAV4 | AWD | Front Right | ||
| 2005 | Toyota | RAV4 | FWD | Front Right | ||
| 2004 | Toyota | RAV4 | Front Right | Install sensor and follow OEM factory relearn procedure, no programming required. | ||
| 2004 | Toyota | RAV4 | AWD | Front Right | ||
| 2004 | Toyota | RAV4 | FWD | Front Right | ||
| 2003 | Toyota | RAV4 | GAS | Front Right | ||
| 2002 | Toyota | RAV4 | GAS | Front Right | ||
| 2001 | Toyota | RAV4 | GAS | Front Right |
* Always verify fitment with your vehicle's VIN if unsure. Submodel & trim restrictions may apply.
This part directly replaces or is cross-referenced with the following part numbers:
Cross-reference numbers are provided for identification purposes only. Always confirm fitment before ordering.
