Standard Ignition CBS-1364 Headlight Dimmer Switch
| Brand | Standard Ignition CBS-1364 |
|---|---|
| Attachment Method | Bolt On |
| Color | Black, White,Yellow |
| Connector Gender | Female; Male |
| Connector Shape | Rectangular |
| Cruise Control Cancel Included | Yes |
| Cruise Control On/Off Operator Inc | No |
| Cruise Control Options Included | Resume, Set, Cancel |
| Cruise Control Resume Included | Yes |
| Cruise Control Set Included | Yes |
| Cruise Control Speed Adjustment In | Yes |
| Displayed | Yes |
| Finish | Plastic |
| Fog Light Operator Included | No |
| Functions | Combination Switch |
| Hardware Included | No |
| Indicator Markings Included | Yes |
| Latching High Beam Operator Includ | Yes |
| Lighting Controls Included | Headlights; High Beams |
| Main Light Operator Included | Yes |
| Momentary High Beam Flasher Includ | Yes |
| New or Reman | New |
| Number Of Connector Cavities | 4 |
| Number Of Wiper Delay Settings | 3 |
| Number Of Wiper Speed Settings | 3 |
| Rear Window Washer Spray Included | No |
| Rear Window Wiper Delay Control In | No |
| Rear Window Wiper Speed Setting In | No |
| Running Light Operator Included | No |
| Terminal Gender | Male; Female |
| Terminal Type | Blade; Pin |
| Turn Signal Control Included | Turn Signal Control |
| Turn Signal/Directional Indicator | Yes |
| Voltage | 12 |
| Windshield Washer Spray Included | Yes |
| Windshield Wiper Delay Setting Inc | Yes |
| Windshield Wiper Speed Setting Inc | Yes |
| Wiper Control Options Included | Windshield on/off; Mist |
| Wire Length (in) | 34.25 |
| Wire Length (mm) | 869.95 |
| Fits | Suzuki · 6 vehicles |
Bolt-on installation. Directly replaces the switch with no modifications needed.
Combination switch. Controls headlights, high beams, turn signals, and wipers.
Cruise control included. Adds resume, set, cancel, and speed adjustment functions.
Cross-references Standard Ignition CBS-1364, 3740066D40 and DL6764 for the same application. See all 5.
Headlight Dimmer Switch for Suzuki Grand Vitara and XL-7
Standard Ignition CBS-1364 is a combination switch built for vehicles with integrated lighting, wiper, washer, and cruise control functions. It is a direct replacement style headlight dimmer switch for select Suzuki applications, including 1999-2002 Suzuki Grand Vitara and 2002 Suzuki XL-7.
Key Features
- Bolt-on attachment with a rectangular 4-cavity connector layout
- Controls headlights, high beams, turn signals, windshield wiper delay, wiper speed, and washer spray
- Includes cruise control resume, set, cancel, and speed adjustment functions
- Features latching high beam, momentary high beam flasher, and main light operator functions
- Black, white, and yellow plastic finish with indicator markings
- New replacement part with 34.25 in. wire length and 24-wire construction
Detailed Description
Standard Ignition CBS-1364 is a headlight dimmer switch and combination switch assembly for select Suzuki Grand Vitara and Suzuki XL-7 models. It combines lighting control, turn signal control, windshield wiper and washer functions, and cruise control inputs into one steering-column-mounted switch assembly. This part number CBS-1364 is listed for 1999-2002 Suzuki Grand Vitara and 2002 Suzuki XL-7, including applications noted for vehicles with cruise control.
The switch includes headlight and high beam operation, turn signal directional indicator control, windshield on/off and mist functions, windshield washer spray, and three wiper delay and speed settings. Cruise control functions include resume, set, cancel, and speed adjustment. Standard Ignition CBS-1364 is a practical replacement for drivers searching for a Suzuki Grand Vitara headlight dimmer switch, Suzuki XL-7 combination switch, or a cruise control-equipped steering column switch.
This part cross-references 3740066D40 and DL6764 for the same application.
What It Is Used For
- Restoring headlight dimmer and high beam switching
- Replacing a worn turn signal or directional indicator control
- Correcting intermittent windshield wiper delay or speed operation
- Repairing washer spray or mist function issues at the steering column
- Restoring cruise control resume, set, and cancel inputs
Installation Notes and Tips
Verify connector style, terminal count, and vehicle equipment before installation. This switch uses a bolt-on attachment method and a 4-connector cavity layout with male and female terminals. Confirm the vehicle is equipped for the listed cruise control and wiper functions, and compare the original switch to CBS-1364 before removal.
Quality Assurance
Standard Ignition supplies this as a new replacement electrical switch assembly for select Suzuki applications. Fitment is listed for 1999-2002 Suzuki Grand Vitara and 2002 Suzuki XL-7, with notes for cruise control-equipped Grand Vitara models.
| Year | Make | Model | Liters | Cylinders | Position | Notes |
|---|---|---|---|---|---|---|
| 2002 | Suzuki | Grand Vitara | — | — | N/A | Brake Light Switch for vehicles with Cruise Control. |
| 2002 | Suzuki | XL-7 | — | — | N/A | — |
| 2002 | Suzuki | XL-7 | 2.7L | V6 | N/A | — |
| 2001 | Suzuki | Grand Vitara | — | — | N/A | Brake Light Switch for vehicles with Cruise Control. |
| 2000 | Suzuki | Grand Vitara | — | — | N/A | Brake Light Switch for vehicles with Cruise Control. |
| 1999 | Suzuki | Grand Vitara | — | — | N/A | Brake Light Switch for vehicles with Cruise Control. |
