Standard Ignition CBS-1664 Headlight Dimmer Switch
| Brand | Standard Ignition CBS-1664 |
|---|---|
| Attachment Method | Bolt On |
| Color | Black |
| Connector Gender | Female |
| Connector Shape | Square |
| Contents | Switch |
| Cruise Control Cancel Included | No |
| Cruise Control On/Off Operator Inc | No |
| Cruise Control Resume Included | No |
| Cruise Control Set Included | No |
| Cruise Control Speed Adjustment In | No |
| Displayed | Yes |
| Finish | Plastic |
| Fog Light Operator Included | No |
| Functions | Combination Switch |
| Indicator Markings Included | Yes |
| Latching High Beam Operator Includ | Yes |
| Main Light Operator Included | No |
| Momentary High Beam Flasher Includ | Yes |
| New or Reman | New |
| Number Of Connector Cavities | 1 |
| Number Of Wiper Delay Settings | 3 |
| Number Of Wiper Speed Settings | 3 |
| Rear Window Washer Spray Included | No |
| Rear Window Wiper Delay Control In | No |
| Rear Window Wiper Speed Setting In | No |
| Running Light Operator Included | No |
| Terminal Gender | Male |
| Terminal Type | Blade |
| Turn Signal Control Included | Yes |
| Turn Signal/Directional Indicator | Yes |
| Voltage | 12 |
| Windshield Washer Spray Included | Yes |
| Windshield Wiper Delay Setting Inc | Yes |
| Windshield Wiper Speed Setting Inc | Yes |
| Fits | Honda · 3 vehicles |
Bolt-on installation. Female connector and 12-blade terminals simplify replacement.
Combination switch. Combines turn signal, wiper, and washer controls in one unit.
New plastic finish. Black housing with indicator markings for clear operation.
Cross-references Standard Ignition CBS-1664, 35256SJCA01 and DL7064 for the same application. See all 5.
Headlight Dimmer Switch for Honda Ridgeline
Restore reliable lighting control with this Standard Ignition headlight dimmer switch, part number CBS-1664. It is a direct electrical replacement for select 2006-2008 Honda Ridgeline models and combines headlight dimmer, turn signal, windshield wiper, and washer functions in one switch assembly.
Key Features
- Standard Ignition CBS-1664 replacement switch
- Compatible with 2006-2008 Honda Ridgeline applications
- Combination switch with turn signal control included
- Latching high beam operator and momentary high beam flasher included
- Windshield washer spray, wiper delay, and wiper speed functions included
- 3 windshield wiper delay settings and 3 wiper speed settings
- Black plastic finish with square female connector
- Bolt-on attachment method with 12 blade terminals
- 12-volt electrical design
Detailed Description
Standard Ignition CBS-1664 is a new headlight dimmer switch built for vehicles that use a combination steering-column control for lighting and wiper operation. For the Honda Ridgeline, this switch supports high beam selection, turn signal operation, windshield washer spray, and adjustable wiper delay and speed settings. The black plastic housing and single square connector are designed to match the original electrical layout for a straightforward replacement. This part cross-references Honda OE-style applications such as 35256SJCA01 and aftermarket references including DL7064 for the same application.
Fits 2006-2008 Honda Ridgeline, N/A. Fits 2006-2008 Honda Ridgeline, N/A. Fits 2006-2008 Honda Ridgeline, N/A.
Common Problems This Part Can Address
- Intermittent or non-working high beam switching
- Turn signal control failure at the steering column
- Inoperative windshield washer spray function
- Wiper delay or speed settings that do not respond correctly
- Worn or damaged combination switch contacts
Installation Notes and Tips
This switch uses a bolt-on attachment method and a single female square connector with blade terminals. Verify connector shape, terminal count, and vehicle application before installation on a 2006-2008 Honda Ridgeline. Confirm that the existing steering-column switch layout matches the combination-switch design and transfer any trim or column components carefully during service.
Quality Assurance
Standard Ignition supplies this CBS-1664 switch as a new replacement electrical component for direct-fit service on listed Honda Ridgeline applications. The part is built to match the original function set for headlight dimming, turn signals, and wiper/washer control.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2008 | Honda | Ridgeline | N/A | — |
| 2007 | Honda | Ridgeline | N/A | — |
| 2006 | Honda | Ridgeline | N/A | — |
