Standard Ignition DWS2211 Door Lock Switch - Front Left

Door Lock Switch for Lexus NX Applications

Standard Ignition DWS2211 is a door lock switch built for front left driver-side use on select Lexus NX models. It is a direct-fit electrical switch assembly with a black and white plastic and metal finish, made for vehicles that use a 20-terminal, female connector with male blade terminals.

Use this switch when you need a replacement for the driver door lock control on compatible Lexus NX300, NX300h, and NX200t models. Standard Ignition DWS2211 is shaped for snap/bolt-in attachment and uses a single polygon connector for a secure electrical connection.

Key Features

• Door lock switch for front left applications
• Standard Ignition DWS2211 replacement part
• 20-terminal design with female connector and male blade terminals
• Snap/bolt-in attachment method
• Black and white plastic and metal construction
• Single polygon connector layout

Detailed Product Description

Standard Ignition DWS2211 is a replacement door lock switch for the driver-side front left position. It is engineered for select Lexus NX300, Lexus NX300h, and Lexus NX200t vehicles and is identified by part number DWS2211. The switch functions as the electrical control point for door lock operation and is built with a 20-terminal configuration, one connector, and blade-style terminals for the specified application.

This part cross-references 8404078010 and PA5104 for the same application. If you are searching for a Lexus NX300 door lock switch front left, a Lexus NX300h driver door lock switch, or a Lexus NX200t front left lock switch, DWS2211 is the matching replacement to compare against the original unit.

What This Part Helps Address

• Inoperative driver door lock switch
• Intermittent lock or unlock response at the front left door
• Broken or worn switch contacts
• Electrical connection issues at the door switch assembly
• Replacement needs after switch housing or button wear

Installation Notes and Tips

Verify connector shape, terminal count, and mounting style before installation. This switch uses a female connector with male blade terminals and a snap/bolt-in attachment method, so the replacement should match the original door panel configuration on the vehicle. Confirm front left placement and compare the original part number when servicing Lexus NX300, NX300h, or NX200t models.

Quality Assurance

Standard Ignition supplies replacement electrical components for automotive service applications, and DWS2211 is built to match the specified connector and mounting requirements for the listed Lexus fitments.
