Standard Ignition EGV505 EGR Valve

Standard Ignition EGV505 EGR Valve

The Standard Ignition EGV505 is an electronic exhaust gas recirculation valve built for direct-fit replacement on select Chrysler and Dodge vehicles. It uses stainless steel valve components and a polyester-reinforced silicone diaphragm to handle heat and long-term service in demanding emission control applications.

Key Features

• Electronic EGR valve for precise exhaust gas recirculation control
• Stainless steel valve components for added durability
• Polyester-reinforced silicone diaphragm resists thermal aging up to 200°C
• Stainless steel gasket included for complete replacement
• Direct-fit design supports straightforward installation
• Female oval connector with 2 male pin terminals
• 2-bolt mounting pattern with 1 hose connector

Detailed Description

Standard Ignition EGV505 is an exhaust gas recirculation valve engineered for emission control service on 1995-1997 Chrysler Intrepid, 1995-1997 Chrysler LHS, 1995-1997 Dodge Intrepid, 1995-1996 Chrysler Concorde, and 1995-1996 Chrysler New Yorker applications. The electronic design helps regulate exhaust flow through the EGR system, while the stainless steel construction and heat-resistant diaphragm support durability in high-temperature operation. This part number, EGV505, is a direct-fit replacement that follows the original connector and mounting layout for easier service. This part cross-references 2-3210 and EGR1085 for the same application.

Common Issues This Part May Address

• EGR-related fault codes
• Rough idle caused by improper exhaust gas recirculation
• Engine hesitation during light-load operation
• Emissions test failure tied to EGR valve malfunction
• Sticking or leaking EGR valve operation

Installation Notes and Tips

Verify the connector shape, terminal count, and 2-bolt mounting pattern before installation. The included gasket supports a complete replacement at the mounting surface. Clean the mating surfaces and inspect the EGR passages for carbon buildup before installing the new valve. Confirm vehicle application by year, make, and model before ordering EGV505.

Quality Assurance

Standard Ignition builds this EGR valve with stainless steel components and a reinforced silicone diaphragm to support durability in elevated temperatures. The direct-fit configuration is intended to match the original part layout on listed Chrysler and Dodge applications.
