Standard Ignition FLS216 Washer Fluid Level Sensor
| Brand | Standard Ignition FLS216 |
|---|---|
| Connector Gender | Female |
| Connector Type | Plug In |
| Contents | Secondary Throttle Diaphragm & Hinge |
| Terminal Gender | Male |
| Terminal Type | Blade |
| Fits | Mazda · 15 vehicles |
Plug-in connector. Female connector with blade terminals for straightforward replacement.
Direct sensor replacement. Matches the washer fluid level sensor function for a clean swap.
Standard Ignition quality. Backed by a trusted name in replacement electrical parts.
Cross-references Standard Ignition FLS216, FF3386 and FLS790 for the same application. See all 5.
Washer Fluid Level Sensor for Mazda Applications
Standard Ignition FLS216 is a washer fluid level sensor for select Mazda vehicles. It is built with a female plug-in connector, male blade terminals, and a single connector layout for direct electrical connection in the washer system.
Key Features
- Washer fluid level sensor for the windshield washer reservoir
- Female connector with plug-in style connection
- Male blade terminals for secure electrical contact
- Single-connector design for straightforward replacement
- Fits 2014-2020 Mazda 6 and 2013-2020 Mazda CX-5
- Standard Ignition FLS216 part number for application matching
Detailed Description
This washer fluid level sensor monitors washer reservoir fluid level and sends the signal through the vehicle’s electrical system when the washer fluid drops low. Standard Ignition FLS216 is listed for 2014-2020 Mazda 6 and 2013-2020 Mazda CX-5, making it a direct-fit service part for common Mazda washer system repairs. The connector layout includes one female plug-in connector with two male blade terminals for the specified application.
This part cross-references FF3386 and FLS790 for the same application.
What It Helps Solve
- Washer fluid warning light staying on
- Inaccurate washer reservoir level readings
- Electrical connection issues at the reservoir sensor
- Replacement needs after sensor wear or contamination
- Service repair for Mazda 6 and Mazda CX-5 washer system faults
Installation Notes and Tips
Verify connector style, terminal layout, and reservoir sensor location before installation. Confirm the vehicle application by year and model: Fits 2014-2020 Mazda 6, N/A; Fits 2013-2020 Mazda CX-5, N/A. Inspect the harness connector and surrounding washer reservoir components for corrosion, damaged terminals, or fluid contamination during service.
Quality Assurance
Standard Ignition replacement parts are cataloged for application-specific fitment and electrical connection requirements. Use the part number FLS216 to confirm the correct washer fluid level sensor for the listed Mazda vehicles.
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2020 | Mazda | 6 | N/A | — |
| 2020 | Mazda | CX-5 | N/A | — |
| 2019 | Mazda | 6 | N/A | — |
| 2019 | Mazda | CX-5 | N/A | — |
| 2018 | Mazda | 6 | N/A | — |
| 2018 | Mazda | CX-5 | N/A | — |
| 2017 | Mazda | 6 | N/A | — |
| 2017 | Mazda | CX-5 | N/A | — |
| 2016 | Mazda | 6 | N/A | — |
| 2016 | Mazda | CX-5 | N/A | — |
| 2015 | Mazda | 6 | N/A | — |
| 2015 | Mazda | CX-5 | N/A | — |
| 2014 | Mazda | 6 | N/A | — |
| 2014 | Mazda | CX-5 | N/A | — |
| 2013 | Mazda | CX-5 | N/A | — |
