Standard Ignition HLS1735 Instrument Panel Dimmer Switch

Reliable Instrument Panel Dimmer Switch for Ford Trucks

The Standard Ignition HLS1735 instrument panel dimmer switch is designed specifically for Ford F-150, F-250 Super Duty, and F-350 Super Duty models. This switch ensures precise control of your dashboard lighting, maintaining optimal visibility and comfort during night driving.

• Push-on attachment method for secure and straightforward installation
• Durable black plastic finish matching factory components
• Female connector with one connection point for easy wiring
• Twelve male pin terminals providing reliable electrical contact
• Operates on standard 12-volt vehicle electrical systems

Product Features and Specifications

The HLS1735 dimmer switch from Standard Ignition is engineered with a push-on attachment method, allowing for a firm and stable fit within the instrument panel assembly. Its black plastic finish is designed to blend seamlessly with the interior of Ford F-150, F-250 Super Duty, and F-350 Super Duty trucks. The switch features a single female connector and twelve male pin terminals, ensuring compatibility with the vehicle’s existing wiring harness. Operating at 12 volts, this switch meets the electrical requirements of these Ford models, providing consistent dimming control for instrument panel lighting.

Compatible Ford Models and Applications

This instrument panel dimmer switch is compatible with the following Ford trucks:

• Ford F-150
• Ford F-250 Super Duty
• Ford F-350 Super Duty

It is designed to replace faulty or worn dimmer switches that affect dashboard illumination and driver visibility.

Common Issues Addressed by the HLS1735 Dimmer Switch

• Dashboard lights that remain too bright or too dim
• Intermittent or non-responsive instrument panel lighting
• Flickering or inconsistent dimmer switch operation
• Difficulty adjusting instrument panel brightness
• Electrical connection problems due to worn terminals

Installation Notes and Tips

Installation of the Standard Ignition HLS1735 dimmer switch requires accessing the instrument panel area. The push-on attachment method simplifies securing the switch in place without additional hardware. Ensure the vehicle’s battery is disconnected before installation to prevent electrical shorts. Verify that the female connector and male pin terminals align correctly with the vehicle’s wiring harness to avoid damage. Testing the switch function before reassembling the dashboard is recommended to confirm proper operation.

Quality Assurance and Warranty Information

Standard Ignition parts are manufactured to meet or exceed OEM specifications, ensuring reliable performance and durability. The HLS1735 dimmer switch undergoes quality control testing to verify electrical and mechanical integrity. While specific warranty details may vary, Standard Ignition typically offers a limited warranty covering defects in materials and workmanship. Consult product documentation or the supplier for exact warranty terms.
