Standard Ignition LX-644 Ignition Control Module

Ignition Control Module for Distributorless Systems

Standard Ignition LX-644 is an external ignition control module for distributorless ignition systems. It is built for direct bolt-on mounting and uses a 12-volt, 5-terminal blade connection with male terminals for a clean electrical interface.

Compatible With 1989-1994 Mazda MPV, 1991-1994 Mercury Capri, and 1989 Mazda B2600 applications that use the listed module configuration. The LX-644 is a practical replacement for vehicles with the module inside the distributor or an integral module setup, depending on application.

• Distributorless ignition type
• External mounting location
• Bolt-on attachment method
• 5-terminal blade connector with male terminals
• 12-volt electrical system
• Mounting hardware included
• Coil not included

Detailed Product Overview

The Standard Ignition LX-644 ignition control module manages ignition switching for supported distributorless systems. It is specified for external installation and uses a blade-style terminal layout to match the original electrical connection on the listed Mazda MPV, Mercury Capri, and Mazda B2600 applications. This part number, LX-644, is a direct-fit service option for vehicles requiring the same module style and connector configuration.

This part cross-references AMS Automotive 7088 for the same application.

Common Problems This Module Can Address

• Engine no-start caused by ignition module failure
• Intermittent stalling related to ignition signal loss
• Misfire conditions from weak or inconsistent spark control
• Hard starting tied to distributorless ignition control issues
• Loss of ignition output on supported Mazda and Mercury applications

Installation Notes and Tips

Verify the original connector style, terminal count, and mounting style before installation. The LX-644 mounts externally with a bolt-on design and uses male blade terminals, so the harness and mounting surface must match the OE configuration. No instructions are included, so compare the removed module to the replacement part before final assembly.

Quality Assurance

Standard Ignition supplies ignition components for service replacement applications, and LX-644 is built to match the listed electrical and mounting specifications for the confirmed vehicle fitment.

• Fits 1989-1994 Mazda MPV, w/ Module Inside Distributor
• Fits 1991-1994 Mercury Capri, Integral Module
• Fits 1990 Mazda MPV
• Fits 1989 Mazda B2600
