Standard Ignition VG139 Exhaust Gas Recirculation (EGR) Valve Gasket

Standard Ignition VG139 EGR Valve Gasket

Standard Ignition VG139 is a metal exhaust gas recirculation (EGR) valve gasket for select Toyota applications. It is built with a 1/64-inch thickness and a single-port, 2-bolt-hole layout to support a proper seal at the EGR valve mounting point.

Compatible with 1991-1997 Toyota Previa and 1984-1988 Toyota Van, this gasket is also listed for 1989 Toyota Van with OE No. 25620-73010. The VG139 is a direct-fit sealing component for service work on the EGR system.

Key Features

• Part number: VG139
• Exhaust Gas Recirculation (EGR) valve gasket
• Metal construction for sealing durability
• 1 port with 2 bolt holes
• Thickness: 1/64 in. (0.51 mm)
• Dimensions: 2.84 in. length, 1.1 in. width, 0.53 in. inner diameter
• Contents: 10 gaskets

Detailed Description

Standard Ignition VG139 is an EGR valve gasket engineered for emission control service where a secure seal is required between the valve and mating surface. Its metal construction and compact profile help maintain the correct interface dimensions for the listed Toyota Previa and Toyota Van applications. If you are replacing a worn EGR valve gasket on a Toyota Previa or Toyota Van, VG139 provides the specified fitment and sealing geometry for the job.

This part cross-references 2-2635 and EVG135 for the same application.

What It Helps Address

• Exhaust leaks at the EGR valve flange
• Damaged or flattened gasket sealing surfaces
• Service replacement during EGR valve removal
• Loss of proper seal after heat cycling
• Emission system maintenance on Toyota Previa and Toyota Van models

Installation Notes and Tips

• Clean both mating surfaces before installation.
• Inspect the EGR valve flange and mounting surface for warping, carbon buildup, or corrosion.
• Confirm the 2-bolt-hole pattern and single-port layout match the removed gasket.
• Use the correct torque sequence and specification for the vehicle service procedure.
• Verify fitment for 1991-1997 Toyota Previa, 1984-1988 Toyota Van, and 1989 Toyota Van with OE No. 25620-73010 before installation.

Quality Assurance

Standard Ignition is a recognized aftermarket brand for emission control service parts. VG139 is listed with defined dimensions, material, and vehicle fitment to support accurate replacement selection for Toyota EGR valve gasket service.
