Standard Ignition VG150 EGR Valve Gasket

Overview of Standard Ignition VG150 EGR Valve Gasket

The Standard Ignition VG150 Exhaust Gas Recirculation (EGR) Valve Gasket is designed for precise sealing in Toyota 4Runner, T100, and Tacoma models. This metal gasket ensures a reliable fit and helps maintain proper emission control system performance.

• Compatible with Toyota 4Runner, T100, and Tacoma vehicles
• Metal construction for durability and heat resistance
• Inner diameter of 0.74 inches (18.81 mm) for accurate sealing
• Length of 2.59 inches (65.79 mm) and width of 1.3 inches (33.02 mm)
• Thickness of 3/64 inches (1.27 mm) with 2 bolt holes for secure installation
• Single port design tailored for specific EGR valve applications

Product Specifications and Features

The VG150 gasket is manufactured from metal to withstand the high temperatures and corrosive environment of the exhaust gas recirculation system. Its dimensions include an inner diameter of 0.74 inches (18.81 mm), length of 2.59 inches (65.79 mm), and width of 1.3 inches (33.02 mm). The gasket thickness is 3/64 inches (1.27 mm), providing a tight seal between the EGR valve and the intake manifold. It features two bolt holes to ensure proper alignment and secure attachment during installation. This gasket does not include a pipe gasket and is designed for a single port EGR valve setup.

Applications and Common Issues Addressed

• Prevents exhaust gas leaks in Toyota 4Runner, T100, and Tacoma EGR systems
• Helps maintain proper engine emissions by sealing the EGR valve connection
• Reduces risk of engine performance issues caused by faulty or leaking gaskets
• Addresses rough idling or check engine light triggers related to EGR valve leaks
• Supports compliance with emission control regulations by ensuring system integrity

Installation Notes and Tips

When installing the Standard Ignition VG150 gasket, ensure the mating surfaces of the EGR valve and intake manifold are clean and free of old gasket material or debris. Align the gasket carefully using the two bolt holes to avoid misplacement. Tighten bolts to manufacturer torque specifications to prevent leaks or damage. This gasket is designed specifically for Toyota 4Runner, T100, and Tacoma models, so verify vehicle compatibility before installation.

Quality Assurance and Warranty

Standard Ignition parts are manufactured to meet or exceed OEM specifications, providing reliable performance in emission control applications. The VG150 EGR valve gasket undergoes quality checks to ensure dimensional accuracy and material integrity. While specific warranty details may vary, Standard Ignition typically offers coverage against defects in material and workmanship to support long-term use in Toyota 4Runner, T100, and Tacoma vehicles.
